Silver 1U rack server chassis, four front 3.5 drive bays, dual 500W PSUs, no bezel or rails

Supermicro

Supermicro SYS-5019C-WR 1U rack server 1x Xeon E-2146G 128GB DDR4 9361-8i 2x 500W

SKU CH-EY5J-5KFP3

1U rack server with Xeon E-2146G, 128 GB DDR4, MegaRAID 9361-8i and dual 500 W platinum supplies

  • Type0
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • AI FeaturesNo
  • CPU TypeIntel Xeon
  • CPU Speed0
  • 1U rackmount server fits dense data-centre deployments
  • Xeon E-2146G 6-core CPU reaches 4.5GHz turbo frequency
  • 128GB DDR4-2666 ECC memory ensures data integrity
  • MegaRAID 9361-8i controller manages eight SAS/SATA drives
  • Dual 500W 80 Plus Platinum PSUs deliver redundant power

1U rack server for enterprise workloads

This 1U rackmount system ships with a single Intel Xeon E-2146G six-core processor running at 3.5 GHz with a 4.5 GHz turbo frequency. It includes 128 GB of DDR4-2666 ECC unbuffered memory across four DIMM slots. The platform targets data-center and business-critical deployments that need compact density with redundant power.

LSI MegaRAID 9361-8i controller with 1 GB cache

Storage is managed by an eight-port SAS 12 Gb/s PCIe RAID controller that supports RAID 0, 1, 5 and 10. The card includes a 1 GB cache backed by a battery module to protect in-flight data during power loss. Four hot-swap 3.5-inch drive bays accept SATA or SAS media, while dual M.2 slots provide additional PCIe 3.0 x4 or SATA connectivity.

Redundant 500 W platinum supplies and IPMI 2.0

Two hot-swap 500 W 80 Plus Platinum power supplies deliver 96 percent efficiency and N+1 redundancy in a 1U chassis. A dedicated RJ45 IPMI 2.0 port with ASPEED AST2500 BMC enables KVM-over-LAN and virtual media for remote management. Expansion includes one PCIe 3.0 x16 or two x8 slots plus a PCIe 3.0 x4 in x8 slot. Front bezel and rack rails are not included.

Highlights

  • 1U rackmount server fits dense data-centre deployments
  • Xeon E-2146G 6-core CPU reaches 4.5GHz turbo frequency
  • 128GB DDR4-2666 ECC memory ensures data integrity
  • MegaRAID 9361-8i controller manages eight SAS/SATA drives
  • Dual 500W 80 Plus Platinum PSUs deliver redundant power

Specifications

BrandSUPERMICRO
SeriesCSE-815TQC-R504WB2
Model0
Part Number3.50 GHz
Type0
Rack Height1U
Redundant Hot-swap PowerYes
AI FeaturesNo
CPU TypeIntel Xeon
CPU Speed0
CPU SocketLGA 1151
Number of CPU Cores6-Core Processor
# of Processors InstalledE-2146G
MAX Processors0
Chipset0
Installed Memory Size128GB
Memory Type0
Max Memory Capacity0
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)0
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerIntegrated Intel 210i-AT Dual Gigabit RJ45 Network Adapter
LAN Ports0
Expansion Slots0
Management PortRJ 45
Operating SystemNo
Features0

Questions about this item

How does the 4.5 GHz turbo speed on the E-2146G behave once the server is under sustained load in a 1U chassis?

The six-core Xeon E-2146G runs at a 3.5 GHz base clock and can reach 4.5 GHz turbo when thermal headroom allows; the 1U form factor and dual 500 W Platinum supplies keep cooling capacity high, but prolonged all-core workloads will settle closer to the base frequency.

What practical throughput limit does the MegaRAID 9361-8i controller impose on the four 3.5-inch drive bays?

The 9361-8i provides eight 12 Gb/s SAS lanes backed by 1 GB cache with battery backup, so the four hot-swap bays can each run at full SATA 6 Gb/s or SAS 12 Gb/s without controller bottleneck.

What mounting hardware is required to install this 1U unit in a standard rack?

The chassis follows the CSE-815TQC-R504WB2 1U specification; front bezel and rack-mount rails are not included, so you must supply compatible slide rails and any cage nuts or screws your rack requires.
