Silver 1U rack server with four front 3.5-inch drive trays and dual rear power supplies

Supermicro

Supermicro SYS-5019C-WR 1U rack server 1x Xeon E-2146G 64GB DDR4 9361-8i 4x 3.5" trays 2x 500W PSUs

SKU CH-BMVM-FW7S8

1U rack server with single Xeon E-2146G, 64 GB DDR4 ECC, MegaRAID 9361-8i controller, four 3.5" hot-swap bays and redundant 500 W Platinum power supplies

  • Type0
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • AI FeaturesNo
  • CPU TypeIntel Xeon
  • CPU Speed0
  • Ready for enterprise workloads with Xeon E-2146G 6-core 3.5 GHz CPU
  • 64 GB DDR4 ECC memory protects data integrity for critical applications
  • MegaRAID 9361-8i controller delivers hardware RAID 0, 1, 5, 10 across 4 hot-swap bays
  • Dual 500 W Platinum power supplies provide 96 % efficiency and redundancy
  • IPMI 2.0 with dedicated LAN enables remote KVM and virtual media management

1U Xeon E-2146G Server

This 1U rackmount server ships new with a 6-core Intel Xeon E-2146G processor at 3.5 GHz and 4.5 GHz turbo. It includes 64 GB DDR4-2666 ECC memory across four DIMM slots and a MegaRAID 9361-8i controller with 1 GB cache. Dual 500 W 80 Plus Platinum supplies provide redundant hot-swap power in a compact chassis.

Suited for virtualisation hosts needing ECC RAM

The single-socket design limits multi-processor scaling and maximum memory to 128 GB. Only four 3.5-inch hot-swap bays are populated so storage density stays modest. Buyers who need dual CPUs, more drive bays or larger memory capacity should consider a larger platform.

Key spec: MegaRAID 9361-8i with 1 GB cache

This controller delivers eight SAS 12 Gb/s ports and hardware RAID 0, 1, 5 and 10 backed by a battery-protected cache. It determines the storage performance and data-protection level for the four drive bays. Confirm the RAID feature set matches your workload before purchase.

Highlights

  • Ready for enterprise workloads with Xeon E-2146G 6-core 3.5 GHz CPU
  • 64 GB DDR4 ECC memory protects data integrity for critical applications
  • MegaRAID 9361-8i controller delivers hardware RAID 0, 1, 5, 10 across 4 hot-swap bays
  • Dual 500 W Platinum power supplies provide 96 % efficiency and redundancy
  • IPMI 2.0 with dedicated LAN enables remote KVM and virtual media management

Specifications

BrandSUPERMICRO
SeriesCSE-815TQC-R504WB2
Model0
Part Number3.50 GHz
Type0
Rack Height1U
Redundant Hot-swap PowerYes
AI FeaturesNo
CPU TypeIntel Xeon
CPU Speed0
CPU SocketLGA 1151
Number of CPU Cores6-Core Processor
# of Processors InstalledE-2146G
MAX Processors0
Chipset0
Installed Memory Size64GB
Memory Type0
Max Memory Capacity0
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)0
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerIntegrated Intel 210i-AT Dual Gigabit RJ45 Network Adapter
LAN Ports0
Expansion Slots0
Management PortRJ 45
Operating SystemNo
Features0

Questions about this item

Does the server include any hard drives or must I supply my own 3.5" SAS/SATA drives?

The unit ships with four 3.5" drive trays and no hard disk drives; you must provide SAS or SATA drives separately.

Which memory configuration should I pick if the system already has 64GB DDR4-2666 ECC installed?

The board holds 128GB maximum across four slots; the current 64GB kit fills all slots, so any upgrade means replacing the existing modules.

How does the Xeon E-2146G 3.5GHz base clock behave under sustained load in this 1U chassis?

The 6-core processor can reach 4.5GHz turbo, but the 1U cooling and 500W platinum power supplies will throttle clocks to stay within thermal limits during continuous workloads.
