Silver 1U rack server with four front 3.5 inch drive bays and dual rear power supplies

Supermicro

Supermicro SYS-5019C-WR 1U rack server Xeon E-2146G 32GB DDR4 9361-8i 4-bay 2x 500W

SKU CH-6H59-Y1TMA

1U rack server with Xeon E-2146G, 32GB DDR4, MegaRAID 9361-8i controller, four hot-swap 3.5" bays and redundant 500W Platinum power supplies

  • Type0
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • AI FeaturesNo
  • CPU TypeIntel Xeon
  • CPU Speed0
  • 1U rackmount form factor fits dense server deployments
  • Intel Xeon E-2146G 6-core CPU reaches 4.5 GHz turbo
  • 32 GB DDR4 ECC memory supports error-correcting workloads
  • MegaRAID 9361-8i controller provides 8-port SAS 12 Gb/s RAID
  • Redundant 500 W 80 Plus Platinum power supplies ensure uptime

1U Xeon E-2146G server

The Supermicro SYS-5019C-WR is a 1U rackmount server system built for enterprise and data centre workloads. It ships with an Intel Xeon E-2146G 3.5 GHz six-core processor running up to 4.5 GHz turbo. The system includes 32 GB of DDR4-2666 ECC memory and an LSI MegaRAID 9361-8i controller with 1 GB cache. Dual 500 W 80 Plus Platinum power supplies provide redundant hot-swap power.

Suits single-socket deployments

This platform suits buyers needing a compact 1U server with hardware RAID and out-of-band management via IPMI 2.0. Four hot-swap 3.5-inch bays support SATA and SAS drives while dual M.2 slots add NVMe or SATA options. Builders who require dual-socket performance, more than four drive bays or front bezel and rails included should look at other configurations.

LGA 1151 socket defines CPU choice

The single LGA 1151 socket limits upgrades to Intel Xeon E-2100, E-2200 series and 8th or 9th Gen Core, Pentium and Celeron processors. Memory tops out at 128 GB across four DIMM slots. Expansion provides one PCIe 3.0 x16 or two x8 slots plus one x4 in x8 form factor.

Highlights

  • 1U rackmount form factor fits dense server deployments
  • Intel Xeon E-2146G 6-core CPU reaches 4.5 GHz turbo
  • 32 GB DDR4 ECC memory supports error-correcting workloads
  • MegaRAID 9361-8i controller provides 8-port SAS 12 Gb/s RAID
  • Redundant 500 W 80 Plus Platinum power supplies ensure uptime

Specifications

BrandSUPERMICRO
SeriesCSE-815TQC-R504WB2
Model0
Part Number3.50 GHz
Type0
Rack Height1U
Redundant Hot-swap PowerYes
AI FeaturesNo
CPU TypeIntel Xeon
CPU Speed0
CPU SocketLGA 1151
Number of CPU Cores6-Core Processor
# of Processors InstalledE-2146G
MAX Processors0
Chipset0
Installed Memory Size32GB
Memory Type0
Max Memory Capacity0
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)0
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerIntegrated Intel 210i-AT Dual Gigabit RJ45 Network Adapter
LAN Ports0
Expansion Slots0
Management PortRJ 45
Operating SystemNo
Features0

Questions about this item

How loud and hot does the 1U chassis get with both 500W Platinum supplies running continuously?

The system uses redundant 500W 80 Plus Platinum power supplies rated at 96 percent efficiency, which reduces waste heat compared with lower-rated units, and the 1U form factor relies on high-speed internal fans to move air through the compact enclosure.

Which drives and caddies must I supply to populate the four 3.5-inch hot-swap bays?

The server ships with four empty 3.5-inch SAS/SATA drive trays; you must provide your own 3.5-inch SATA or SAS hard drives or SSDs to fill them.

Will the LSI MegaRAID 9361-8i controller work with older SATA III drives I already own?

Yes, the 9361-8i supports both SAS and SATA interfaces, so existing SATA III drives can be used in the four hot-swap bays and managed through the hardware RAID controller.
