Silver 1U rack server front with four 3.5 inch drive bays

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2660 v4 2.0GHz 14C 32GB DDR4 4x 3.5" bays

SKU CH-F2YA-PT2P2

1U rack server with dual 14-core Xeon processors at 2.0 GHz, 32 GB DDR4 ECC, MegaRAID 9361-8i, four 3.5-inch hot-swap bays, quad 10GBase-T ports, IPMI 2.0, and redundant 750 W power supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.00 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores14-Core Processor
  • Dual 14-core Xeon processors at 2.0 GHz with 3.2 GHz turbo for parallel workloads
  • 32 GB DDR4 2400 MHz registered ECC memory across 4 DIMM slots
  • MegaRAID 9361-8i controller with 1 GB cache and battery supporting RAID 0/1/5/6/10/50/60
  • Four 3.5" hot-plug SATA/SAS drive bays with trays included
  • Quad 10GBase-T RJ45 ports via Intel X540 plus dedicated IPMI 2.0 management LAN

Dual-socket Xeon 1U server

The Supermicro SYS-6018U-TR4T+ is a 1U rackmount server built around two Intel Xeon E5-2660 v4 processors. Each CPU runs at 2.0GHz with 14 cores and reaches 3.2GHz turbo frequency. The system ships with 32GB of DDR4 2400MHz registered ECC memory installed across four modules. It is aimed at organisations that need dense compute for virtualisation, HPC or cloud workloads in a single rack unit.

Redundant 750W platinum power

Two hot-swap 750 watt platinum-efficiency power supplies provide full redundancy and reduce waste heat during normal operation. The 1U chassis uses Supermicro's thermal design to keep dual 14-core processors and the LSI MegaRAID 9361-8i controller within safe limits while fan noise remains typical for a data-centre 1U platform. A dedicated RJ45 IPMI 2.0 port allows remote monitoring of temperatures, power draw and fan speeds without loading the main operating system.

Four 3.5-inch hot-plug bays

Only four 3.5-inch SAS/SATA drive trays are included, so buyers who need more storage slots or 2.5-inch bay density must choose a different chassis. The MegaRAID 9361-8i supports RAID 0, 1, 5, 6, 10, 50 and 60 with 1GB cache and battery backup. Quad 10GBase-T ports on the Intel X540 controller handle high-throughput networking. The Matrox G200 with 8MB video memory provides basic console output only.

Highlights

  • Dual 14-core Xeon processors at 2.0 GHz with 3.2 GHz turbo for parallel workloads
  • 32 GB DDR4 2400 MHz registered ECC memory across 4 DIMM slots
  • MegaRAID 9361-8i controller with 1 GB cache and battery supporting RAID 0/1/5/6/10/50/60
  • Four 3.5" hot-plug SATA/SAS drive bays with trays included
  • Quad 10GBase-T RJ45 ports via Intel X540 plus dedicated IPMI 2.0 management LAN

Specifications

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.00 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors InstalledE5-2660 V4
Installed Memory Size32GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

How do I install the Xeon E5-2660 v4 processors and what step is often missed?

Align the LGA 2011-3 CPUs in the dual sockets, close the retention levers, then seat the 32GB DDR4 2400MHz registered ECC DIMMs across the 24 slots in the correct population order for dual-processor operation.

What maintenance will the MegaRAID 9361-8i controller need over time?

The 1GB cache module includes a battery that will degrade; plan to replace the battery backup unit when the controller logs a cache-protection warning.

What limit appears first when the four 10GBase-T ports run sustained throughput?

The Intel X540 controller and 750W platinum supplies share the 1U thermal envelope; continuous line-rate traffic on all four ports will trigger fan-speed escalation before the network interface saturates.
