1U silver rack server with four front drive trays

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2695 v4 18-core 128GB DDR4 4x 3.5" trays

SKU CH-8KEN-N8D8T

1U rack server with dual 18-core Xeon E5-2695 v4 processors, 128GB DDR4 ECC memory, MegaRAID 9361-8i controller, four 3.5-inch hot-swap drive bays.

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores18-Core Processor
  • Dual 18-core Xeon processors deliver 36 threads at 2.1 GHz base with 3.3 GHz turbo
  • 128 GB DDR4 ECC memory across 8 modules runs at 2400 MHz for error-free throughput
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache and battery backup
  • Four 3.5-inch hot-swap bays accept SATA or SAS drives for flexible storage density
  • Quad 10GBase-T ports plus dedicated IPMI 2.0 LAN enable high-speed data and remote management

Dual Xeon E5-2695 v4 1U Server

The Supermicro SYS-6018U-TR4T+ is a 1U rackmount server system fitted with two Intel Xeon E5-2695 v4 processors. Each CPU provides 18 cores at 2.10 GHz with a 3.3 GHz turbo frequency. The platform includes 128GB of DDR4 2400MHz registered ECC memory across eight modules and a MegaRAID 9361-8i controller with 1GB cache and battery backup.

Suits virtualisation and dense compute.

This server targets environments that need high core counts and 10GBase-T networking in a single rack unit, such as virtualisation hosts, HPC nodes or cloud infrastructure. The Matrox G200 graphics with 8MB video memory and the absence of PCIe expansion slots in the specifications mean it cannot serve workloads that require dedicated GPU acceleration or additional add-in cards.

Four 3.5-inch hot-plug bays with SAS/SATA support

Storage connectivity is limited to the four front-accessible 3.5-inch drive trays wired to the onboard SATA/SAS interface and the 9361-8i RAID controller. The system ships without hard drives, so buyers must provide their own SAS or SATA disks to populate the bays and configure the desired RAID level from the supported 0, 1, 5, 6, 10, 50 or 60 options.

Highlights

  • Dual 18-core Xeon processors deliver 36 threads at 2.1 GHz base with 3.3 GHz turbo
  • 128 GB DDR4 ECC memory across 8 modules runs at 2400 MHz for error-free throughput
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache and battery backup
  • Four 3.5-inch hot-swap bays accept SATA or SAS drives for flexible storage density
  • Quad 10GBase-T ports plus dedicated IPMI 2.0 LAN enable high-speed data and remote management

Specifications

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors InstalledE5-2695 V4
Installed Memory Size128GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

How loud and hot does the 1U chassis get with both E5-2695 v4 CPUs running at 2.1 GHz all day?

The 1U form factor uses high-speed fans to move air through the heatsinks; expect noticeable fan noise and warm exhaust when both 18-core Xeons sustain load.

Which drives and rails must I supply to use the four 3.5" hot-plug bays and mount the server?

You need 3.5" SATA or SAS hard drives or SSDs and standard 1U rack rails; the front bezel and rails are not included.

Will the LSI MegaRAID 9361-8i and the Intel X540 10GBase-T ports work with my older SATA drives and 1 GbE switches?

The 9361-8i supports SATA and SAS drives at 12 Gb/s, and the X540 ports auto-negotiate down to 1 GbE on legacy switches.
