Silver 1U rack server chassis with four front 3.5-inch drive trays

Supermicro

Supermicro SYS-6018U-TR4T+ 1U rack server 2x Xeon E5-2697 v4 256GB DDR4 4x 3.5" trays

SKU CH-NQHS-KFZ6A

1U rack server with dual 18-core Xeon E5-2697 v4 CPUs, 256GB DDR4, MegaRAID 9361-8i, four 3.5" hot-swap bays and quad 10GBase-T ports

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.30 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores18-Core Processor
  • Dual 18-core Xeon E5-2697 v4 CPUs at 2.3 GHz with 3.6 GHz Turbo
  • 256 GB DDR4 2400 MHz registered ECC memory across 8 modules
  • MegaRAID 9361-8i controller with 1 GB cache and battery backup supporting RAID 0/1/5/6/10/50/60
  • Quad 10GBase-T Ethernet ports via Intel X540 for high-speed networking
  • Dual 750 W platinum-efficiency hot-swap power supplies for redundant power

Dual Xeon 1U server for dense compute

The Supermicro SYS-6018U-TR4T+ is a 1U rackmount server fitted with two Intel Xeon E5-2697 v4 processors, each running 18 cores at 2.3 GHz with a 3.6 GHz turbo. It ships with 256 GB of DDR4 2400 MHz registered ECC memory across 24 DIMM slots. The platform targets virtualisation, HPC and cloud workloads that demand high core counts in a single rack unit.

Check power, rails and drive count before ordering

The system includes two 750 W platinum redundant hot-swap power supplies and requires suitable PDU connectors. Front bezel and rack-mount rails are not included, so verify cabinet depth and rail kit compatibility. Only four 3.5-inch hot-plug trays are supplied; the chassis supports up to ten 2.5-inch bays, but additional trays and drives must be sourced separately.

Adds quad 10GBase-T and hardware RAID to a rack row

A MegaRAID 9361-8i controller with 1 GB cache and battery backs RAID 0, 1, 5, 6, 10, 50 and 60 across SATA or SAS drives. The AOC-UR-i4XT card provides four RJ45 10GBase-T ports via Intel X540, while a dedicated RJ45 IPMI 2.0 port enables KVM-over-LAN and virtual media. The Matrox G200 GPU handles basic video output for management tasks.

Highlights

  • Dual 18-core Xeon E5-2697 v4 CPUs at 2.3 GHz with 3.6 GHz Turbo
  • 256 GB DDR4 2400 MHz registered ECC memory across 8 modules
  • MegaRAID 9361-8i controller with 1 GB cache and battery backup supporting RAID 0/1/5/6/10/50/60
  • Quad 10GBase-T Ethernet ports via Intel X540 for high-speed networking
  • Dual 750 W platinum-efficiency hot-swap power supplies for redundant power

Specifications

BrandSUPERMICRO
SeriesCSE-819U + X10DRU-i+
ModelSYS-6018U-TR4T+
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.30 GHz
CPU SocketLGA 2011-3
Number of CPU Cores18-Core Processor
# of Processors InstalledE5-2697 V4
Installed Memory Size256GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerSupermicro AOC-UR-i4XT - Intel X540 - 4x RJ45 10GBase-T Ports
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

Does the server ship with hard drives or only the four 3.5" trays?

The unit includes four 3.5" hot-plug SAS/SATA trays; no hard drives are installed, so drives must be purchased separately.

Should I choose the dual Xeon E5-2697 v4 configuration or a single-processor option?

This model comes with two E5-2697 v4 processors already installed, providing 36 cores total; there is no single-processor version of this SKU.

What does the 2.3 GHz base clock mean when both 18-core CPUs are under load?

Each Xeon E5-2697 v4 runs at 2.3 GHz base and can turbo to 3.6 GHz, giving 36 cores of processing power for virtualization or HPC workloads.
