Silver 1U rack server, four 3.5 inch drive bays front, dual redundant power supplies rear

Supermicro

Supermicro SYS-6019U-TN4R4T 1U rack server 2x Xeon 8160 64GB DDR4 4x 3.5" bays 9361-8i X540 2x 750W

SKU CH-GZ2G-RTBNP

Dual 24-core Xeon 8160 processors, 64 GB DDR4, MegaRAID 9361-8i controller, four 3.5″ hot-swap bays, quad 10GBase-T ports, IPMI 2.0 and redundant 750 W PSUs in a 1U chassis

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores24-Core Processor
  • Dual Xeon Platinum 8160 processors provide 24 cores each at 2.1 GHz
  • 64 GB DDR4 ECC registered memory supports virtualisation and large datasets
  • MegaRAID 9361-8i controller enables RAID 0/1/5/6/10/50/60 with 1 GB cached battery backup
  • Four 10GBase-T ports via Intel X540 give high-speed network connectivity
  • Redundant hot-swap 750 W platinum power supplies maintain uptime

1U Dual Xeon 8160 Server 64GB DDR4

The Supermicro SYS-6019U-TN4R4T is a 1U rackmount server system built around two Intel Xeon Platinum 8160 processors. Each CPU delivers 24 cores at 2.1 GHz with 3.7 GHz turbo capability. The system ships with 64 GB of DDR4-2666 ECC registered memory across four 16 GB modules. A MegaRAID 9361-8i controller provides eight SAS 12 Gb/s ports with 1 GB cached battery backup.

Suits compute-dense virtualization and HPC clusters

This configuration fits workloads that demand high core counts and fast 10 GbE networking in a single rack unit. Four hot-swap 3.5-inch bays support SATA or SAS drives for capacity-oriented storage. Buyers who need more than four drive bays or require additional PCIe expansion slots should evaluate larger chassis options. The integrated Matrox G200 graphics with 8 MB video memory covers basic console output only.

Four 3.5-inch hot-swap bays with SAS/SATA

The chassis provides exactly four front-accessible 3.5-inch trays connected to the 9361-8i RAID controller supporting RAID 0, 1, 5, 6, 10, 50 and 60. Dual 750 W platinum-efficiency power supplies deliver redundant hot-swap power. IPMI 2.0 with a dedicated RJ45 management port enables remote KVM and virtual media. Front bezel and rack rails are not included.

Highlights

  • Dual Xeon Platinum 8160 processors provide 24 cores each at 2.1 GHz
  • 64 GB DDR4 ECC registered memory supports virtualisation and large datasets
  • MegaRAID 9361-8i controller enables RAID 0/1/5/6/10/50/60 with 1 GB cached battery backup
  • Four 10GBase-T ports via Intel X540 give high-speed network connectivity
  • Redundant hot-swap 750 W platinum power supplies maintain uptime

Specifications

BrandSUPERMICRO
SeriesCSE-819UTS-R751P-T-X11DPU
ModelSYS-6019U-TN4R4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores24-Core Processor
# of Processors InstalledPlatinum 8160
Installed Memory Size64GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via AOC-UR-i4XT (Intel X540 10GBase-T)
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays
