Silver 1U rack server front with four 3.5 inch drive trays and status LEDs

Supermicro

Supermicro SYS-6019U-TN4R4T 1U rack server 2x Xeon Gold 5118 2.3GHz 256GB DDR4

SKU CH-030X-WBNH9

A 1U rack server with dual 12-core Xeon Gold 5118 CPUs, 256GB DDR4 ECC memory, four hot-swap 3.5" drive bays, MegaRAID 9361-8i controller, four 10GBase-T ports and redundant 750W power supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.30 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores12-Core Processor
  • Dual Xeon Gold 5118 CPUs deliver 24 cores at 2.3 GHz with 3.2 GHz turbo
  • 256 GB DDR4 2400 MHz ECC registered memory ensures data integrity
  • MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Four 10GBase-T ports via Intel X540 provide high-speed networking
  • IPMI 2.0 with dedicated LAN enables remote KVM and virtual media management

Dual Xeon Gold 5118 1U server

The Supermicro SYS-6019U-TN4R4T is a 1U rack server equipped with two Intel Xeon Gold 5118 processors running at 2.3 GHz with 12 cores each. It ships with 256 GB of DDR4 2400 MHz registered ECC memory installed across eight 32 GB modules. The system targets virtualisation hosts, high-performance compute clusters and software-defined storage nodes that need dense compute in a single rack unit.

MegaRAID 9361-8i and quad 10GBase-T

An LSI MegaRAID 9361-8i controller provides eight internal SAS 12 Gb/s ports with 1 GB cache and battery backup, supporting RAID 0, 1, 5, 6, 10, 50 and 60 across the four hot-swap 3.5-inch drive bays. A dedicated AOC-UR-i4XT add-on card adds four 10GBase-T Ethernet ports based on the Intel X540 controller. IPMI 2.0 with a dedicated RJ45 management port enables remote KVM, virtual media and out-of-band monitoring without using the data network interfaces.

Verify rack depth and drive supply

The chassis uses the CSE-819UTS-R751P-T-X11DPU series and requires a rack deep enough for a 1U server with redundant 750 W platinum power supplies; front bezel and mounting rails are not included. Four 3.5-inch SAS or SATA drive trays are supplied but no drives are installed, so you must source compatible storage separately. The Matrox G200 graphics with 8 MB video memory only supports basic console output, not graphical workloads.

Highlights

  • Dual Xeon Gold 5118 CPUs deliver 24 cores at 2.3 GHz with 3.2 GHz turbo
  • 256 GB DDR4 2400 MHz ECC registered memory ensures data integrity
  • MegaRAID 9361-8i controller supports RAID 0, 1, 5, 6, 10, 50, 60
  • Four 10GBase-T ports via Intel X540 provide high-speed networking
  • IPMI 2.0 with dedicated LAN enables remote KVM and virtual media management

Specifications

BrandSUPERMICRO
SeriesCSE-819UTS-R751P-T-X11DPU
ModelSYS-6019U-TN4R4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.30 GHz
CPU SocketLGA 3647
Number of CPU Cores12-Core Processor
# of Processors InstalledGold 5118
Installed Memory Size256GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via AOC-UR-i4XT (Intel X540 10GBase-T)
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

Will the MegaRAID 9361-8i controller battery need scheduled replacement?

The 9361-8i includes a 1 GB cache with battery backup; the battery is a consumable part and should be replaced per the controller's maintenance schedule.

What thermal limit appears first when both Xeon Gold 5118 CPUs run at 3.2 GHz turbo continuously?

In a 1U chassis the CPU package temperature threshold is typically reached before the 750 W power supplies reach their capacity ceiling.

How loud are the fans when the server runs 24/7 with both 750 W PSUs active?

Dual 750 W Platinum supplies and dense 1U airflow mean fan speed ramps up under sustained load; expect noticeable acoustic output in a quiet room.
