Silver 1U rack server front with four 3.5-inch drive trays and blue status LEDs

Supermicro

Supermicro SYS-6019U-TN4R4T 1U rack server 2x Xeon Gold 6130 32GB DDR4 4x 3.5" bays

SKU CH-SS1K-ABFK3

1U rack server with dual 16-core Xeon Gold 6130 CPUs, 32GB DDR4 ECC memory, MegaRAID 9361-8i controller, four 3.5-inch hot-swap bays, four 10GBase-T ports and dual 750W power supplies

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores16-Core Processor
  • Dual 16-core Xeon Gold 6130 CPUs deliver high multi-threaded throughput
  • 32GB DDR4-2666 ECC memory ensures data integrity for critical workloads
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1GB cache
  • Four 3.5-inch hot-swap bays enable high-capacity SATA/SAS storage expansion
  • Four 10GBase-T ports plus IPMI 2.0 provide fast networking and remote management

Dual Xeon 1U server with four 3.5" bays

The Supermicro SYS-6019U-TN4R4T is a 1U rackmount server system equipped with two Intel Xeon Gold 6130 processors running at 2.10 GHz with 16 cores each. It includes 32 GB of DDR4-2666 ECC registered memory across four modules. The chassis provides four hot-swap 3.5-inch drive bays supporting SATA and SAS drives connected to an LSI MegaRAID 9361-8i controller with 1 GB cache and battery backup.

Suited for dense virtualization

This server fits environments needing dual-socket compute density and 10 GbE networking in a single rack unit. The four 3.5-inch bays limit internal capacity for deployments requiring many local drives. Buyers needing GPU acceleration should note the only video output is a Matrox G200 with 8 MB memory. The front bezel and rack rails are not included.

Four 3.5-inch hot-swap bays with SAS/SATA RAID

The storage subsystem centres on four front-accessible 3.5-inch trays wired to the MegaRAID 9361-8i controller supporting RAID 0, 1, 5, 6, 10, 50 and 60. This bay count and controller choice determine how much redundant local storage the platform can present to the operating system.

Highlights

  • Dual 16-core Xeon Gold 6130 CPUs deliver high multi-threaded throughput
  • 32GB DDR4-2666 ECC memory ensures data integrity for critical workloads
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1GB cache
  • Four 3.5-inch hot-swap bays enable high-capacity SATA/SAS storage expansion
  • Four 10GBase-T ports plus IPMI 2.0 provide fast networking and remote management

Specifications

BrandSUPERMICRO
SeriesCSE-819UTS-R751P-T-X11DPU
ModelSYS-6019U-TN4R4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores16-Core Processor
# of Processors InstalledGold 6130
Installed Memory Size32GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via AOC-UR-i4XT (Intel X540 10GBase-T)
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What rack-mount rails fit the 1U chassis of the SYS-6019U-TN4R4T?

The 1U server uses Supermicro CSE-819UTS rails; the front bezel and rails are not included so they must be sourced separately.

How do I install the LSI MegaRAID 9361-8i controller and what step is often missed?

Seat the 9361-8i in a PCIe slot, connect the SAS cables to the backplane, then create virtual disks in the Ctrl-R BIOS before the OS sees any volumes.

When will the BBU on the MegaRAID 9361-8i need replacement?

The 1 GB cache battery typically lasts three to five years; the IPMI 2.0 interface will log a BBU fault when capacity drops below threshold.
