Silver 1U rack server front with four 3.5 inch drive bays

Supermicro

Supermicro SYS-6019U-TN4R4T 1U rack server 2x Xeon Platinum 8160 768GB DDR4

SKU CH-RBP8-ZD6MF

1U rack server with dual 24-core Xeon Platinum 8160 CPUs, 768GB DDR4 ECC memory, LSI MegaRAID 9361-8i controller, four 3.5-inch hot-swap bays, quad 10GBase-T ports and IPMI 2.0 management

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores24-Core Processor
  • Dual Xeon Platinum 8160 processors deliver 24 cores each at 2.1 GHz
  • 768 GB DDR4-2666 ECC registered memory across 24 DIMM slots
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Four 10GBase-T ports via Intel X540 for high-speed networking
  • Dual 750 W platinum-efficiency hot-swap power supplies for redundancy

Dense compute in 1U

The Supermicro SYS-6019U-TN4R4T is a 1U rack server built around two Intel Xeon Platinum 8160 processors, each with 24 cores at 2.1 GHz. It ships with 768 GB of DDR4-2666 ECC registered memory across 24 DIMMs. The platform targets virtualization hosts, HPC clusters and software-defined storage nodes that need high core counts in a single rack unit.

Four hot-swap bays and quad 10GbE

The chassis provides four 3.5-inch SATA/SAS hot-plug drive bays backed by an LSI MegaRAID 9361-8i controller with 1 GB cache and battery backup. Network connectivity comes from an AOC-UR-i4XT add-on card delivering four 10GBase-T ports via Intel X540 controllers. A dedicated RJ45 management port enables IPMI 2.0 with virtual media and KVM-over-LAN for lights-out administration.

Redundant 750 W platinum supplies

Dual hot-swap 750 W platinum-efficiency power supplies share the load and allow one unit to fail without downtime. The 1U form factor relies on high-speed internal fans to move air across the dual 24-core CPUs, memory array and RAID controller, so acoustic output is typical for dense rack gear. No front bezel or rack rails are included in the package.

Highlights

  • Dual Xeon Platinum 8160 processors deliver 24 cores each at 2.1 GHz
  • 768 GB DDR4-2666 ECC registered memory across 24 DIMM slots
  • MegaRAID 9361-8i controller supports RAID 0/1/5/6/10/50/60 with 1 GB cache
  • Four 10GBase-T ports via Intel X540 for high-speed networking
  • Dual 750 W platinum-efficiency hot-swap power supplies for redundancy

Specifications

BrandSUPERMICRO
SeriesCSE-819UTS-R751P-T-X11DPU
ModelSYS-6019U-TN4R4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores24-Core Processor
# of Processors InstalledPlatinum 8160
Installed Memory Size768GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via AOC-UR-i4XT (Intel X540 10GBase-T)
Management PortRJ 45
Features4 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What speed does the X540 10GBase-T Ethernet controller cap at in practice?

The four 10GBase-T ports are limited to 10 Gb/s per port by the Intel X540 controller.

What rack depth and rail kit does this 1U chassis require?

The 1U server needs a standard 19-inch rack; rails and front bezel are not included.

How is the MegaRAID 9361-8i controller installed and what step is often missed?

The controller occupies a PCIe slot; the battery-backed cache module must be seated and the battery connected before first boot.
