Silver 2U rack server front with twelve 3.5 inch drive bays

Supermicro

Supermicro SYS-6029U-E1CR4T 2U rack server 2x Xeon Gold 6130 768GB DDR4 12x 3.5" bays

SKU CH-5D91-FMJEX

2U rack server with dual 16-core Xeon Gold 6130 CPUs, 768 GB DDR4, 12 hot-swap 3.5" bays and four 10GbE ports

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.10 GHz
  • CPU SocketLGA 3647
  • Number of CPU Cores16-Core Processor
  • Dual Xeon Gold 6130 CPUs deliver 32 total cores at 2.1 GHz base
  • 768 GB DDR4-2666 ECC memory across 24 DIMM slots supports large datasets
  • MegaRAID 9361-8i controller enables RAID 0/1/5/6/10/50/60 with 1 GB cache
  • 12 hot-swap 3.5″ SAS/SATA drive bays provide high-density local storage
  • Four 10GBase-T ports via Intel X710 plus dedicated IPMI 2.0 LAN for remote management

Dual Xeon Gold 6130 2U server

The Supermicro SYS-6029U-E1CR4T is a 2U rackmount server system built around two Intel Xeon Gold 6130 processors. Each CPU provides 16 cores at 2.1 GHz with a 3.7 GHz turbo frequency. The platform includes 768 GB of DDR4-2666 ECC registered memory across 24 DIMM slots and a MegaRAID 9361-8i controller with 1 GB cache and battery backup.

Virtualisation and storage workloads

This configuration suits organisations running virtualisation clusters, hyper-converged storage or cloud platforms that need dense 3.5-inch drive capacity and dual 10 GbE networking. Four 10GBase-T ports via the Intel X710 adapter and a dedicated IPMI 2.0 management port support remote KVM and virtual media. Buyers who need GPU compute density or front-accessible NVMe bays without extra add-in cards should evaluate alternative platforms.

Sustained load behaviour

Dual 1000 W titanium-efficiency power supplies provide redundant hot-swap power for continuous operation. The 12 hot-plug 3.5-inch SATA/SAS bays allow drive replacement without downtime. Six full-height PCIe 3.0 expansion slots (two x16, four x8) plus one low-profile x8 slot accommodate additional network or storage controllers while maintaining airflow under prolonged heavy utilisation.

Highlights

  • Dual Xeon Gold 6130 CPUs deliver 32 total cores at 2.1 GHz base
  • 768 GB DDR4-2666 ECC memory across 24 DIMM slots supports large datasets
  • MegaRAID 9361-8i controller enables RAID 0/1/5/6/10/50/60 with 1 GB cache
  • 12 hot-swap 3.5″ SAS/SATA drive bays provide high-density local storage
  • Four 10GBase-T ports via Intel X710 plus dedicated IPMI 2.0 LAN for remote management

Specifications

BrandSUPERMICRO
SeriesCSE-829U2E1C4-R1K02-T-X11DPU
ModelSYS-6029U-E1CR4T
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.10 GHz
CPU SocketLGA 3647
Number of CPU Cores16-Core Processor
# of Processors InstalledGold 6130
Installed Memory Size768GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T ports via Intel X710 (AOC-2UR66-i4XTF)
Management PortRJ 45
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What rack-mount hardware do I need to install this 2U server in a standard cabinet?

The chassis requires standard 2U rack rails; the manufacturer notes that rack mount rails are not included with the unit.

Can I keep my existing 3.5-inch SATA drives and use them in the twelve hot-swap bays?

Yes, the twelve 3.5-inch bays accept both SATA and SAS drives through the MegaRAID 9361-8i controller.

How can I confirm the dual Xeon Gold 6130 CPUs and 768GB DDR4 are recognised after first boot?

Enter the BIOS or IPMI 2.0 interface; both will show two 16-core processors at 2.1GHz and 24 DIMM slots populated with 32GB modules.
