Silver 4U rack server with 36 front 3.5-inch drive bays and dual redundant power supplies

Supermicro

Supermicro SYS-6048R-E1CR36N 4U rack server 2x Xeon E5-2667 v4 3.2GHz 8-core 768GB DDR4 36-bay 3.5

SKU CH-210A-ZDX01

A 4U rack server with dual Xeon E5-2667 v4 processors, 768GB DDR4 memory, LSI MegaRAID 9361-8i controller and 36 hot-swap 3.5-inch drive bays

  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed3.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores8-Core Processor
  • Dual Xeon E5-2667 v4 3.2GHz 8-core CPUs deliver high compute throughput
  • 768GB DDR4 2400MHz ECC memory supports large workloads
  • MegaRAID 9361-8i controller provides RAID 0/1/5/6/10/50/60
  • 36 hot-swap 3.5" SATA/SAS drive bays enable massive storage
  • Quad 10GBase-T LAN ports with X540 controller ensure fast networking

High-density 4U storage server

The Supermicro SYS-6048R-E1CR36N is a 4U rackmount system built for high-density storage workloads. It ships with two Intel Xeon E5-2667 v4 processors running at 3.2GHz with 8 cores each and 768GB of DDR4 registered ECC memory installed across 24 DIMM slots. The platform supports the Intel Xeon E5-2600 v4/v3 family for scalable compute performance.

MegaRAID 9361-8i controller and quad 10GbE

An LSI MegaRAID 9361-8i 8-port SAS 12Gb/s RAID controller with 1GB cache and battery backup provides hardware RAID levels 0, 1, 5, 6, 10, 50 and 60 for data protection. Four 10GBase-T LAN ports driven by an Intel X540 controller deliver high-speed network connectivity. IPMI 2.0 with a dedicated RJ45 management port enables KVM-over-LAN and virtual media for remote administration.

Thirty-six hot-swap bays

The chassis holds 36 hot-plug 3.5-inch SAS/SATA drive trays arranged in 24 front and 12 rear bays, allowing massive raw capacity without downtime for drive changes. Two 1280W 80 Plus Platinum redundant hot-swap power supplies maintain uptime during a power-module failure. The front bezel and rack-mount rails are not included, so plan for separate mounting hardware.

Highlights

  • Dual Xeon E5-2667 v4 3.2GHz 8-core CPUs deliver high compute throughput
  • 768GB DDR4 2400MHz ECC memory supports large workloads
  • MegaRAID 9361-8i controller provides RAID 0/1/5/6/10/50/60
  • 36 hot-swap 3.5" SATA/SAS drive bays enable massive storage
  • Quad 10GBase-T LAN ports with X540 controller ensure fast networking

Specifications

BrandSUPERMICRO
SeriesCSE-847BE1C-R1K28LPB-X10DRi-T4+
ModelSYS-6048R-E1CR36N
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed3.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores8-Core Processor
# of Processors InstalledE5-2667 V4
Installed Memory Size768GB
Storage ControllerLSI MegaRAID 9361-8i Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet Controller4x 10GBase-T LAN with Intel X540 Ethernet Controller
Management PortRJ 45
Features36 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

What maintenance will the MegaRAID 9361-8i controller battery need?

The 9361-8i includes a 1 GB cache with a battery backup unit that protects writes during power loss; the battery is a consumable part and should be replaced according to the controller firmware alerts or after several years of continuous operation.

Which limit appears first when all 36 drive bays are active under sustained load?

The 9361-8i provides only 8 internal SAS ports, so the controller port count becomes the bottleneck before the 36 hot-swap bays or the dual 1280 W power supplies reach their limits.

How much heat and noise should I expect from the dual 1280 W Platinum supplies running continuously?

Two 1280 W 80 Plus Platinum units share the load efficiently, but at full 36-bay utilisation the system will draw several hundred watts, generating noticeable fan noise and exhaust heat typical of a densely packed 4U storage server.
