Black 1U rackmount NAS with four drive bays and front LEDs

Synology Inc.

Synology RS826+ AMD Ryzen V1500B 4-Bay Rackmount NAS 32GB 80TB

SKU CH-HBY9-FEZAX

A 1U rackmount NAS with an AMD Ryzen V1500B processor, 32GB DDR4 memory and four 20TB SATA drives delivering 80TB of assembled storage

  • Port RJ-454 x 10/100/1000M
  • Port USB2 x USB 3.2 Gen 1 Ports
  • Form Factor4-Bay
  • ProcessorAMD Ryzen
  • Installed Memory32GB
  • Included HDD Capacity80TB (4 x 20TB)
  • AMD Ryzen V1500B four-core processor powers demanding workloads
  • 32GB DDR4 ECC memory supports virtualisation and multitasking
  • 80TB raw capacity with four 20TB Synology Plus drives
  • Four 1GbE ports enable link aggregation and failover
  • PCIe Gen3 slot allows 10GbE or 25GbE upgrade

Compact 1U rackmount NAS

The Synology RS826+ is a 1U rackmount network-attached storage server built for edge locations and remote offices. It uses a 2.2 GHz AMD Ryzen V1500B four-core processor with eight threads and comes with 32 GB of DDR4 ECC memory. Four drive bays hold the included 20 TB Synology Plus drives for a total of 80 TB raw capacity.

Sustained throughput and expandability

Under Synology test conditions the system delivers more than 2,000 MB/s sequential read and 1,300 MB/s sequential write performance. Four integrated 1 GbE RJ-45 ports support Link Aggregation for load balancing and automatic failover. A PCIe Gen3 expansion slot allows a compatible 10 GbE or 25 GbE adapter to be added when network demands increase.

Interface and environmental limits

The four 1 GbE ports set the baseline network ceiling at 1 GbE per port unless an expansion card is installed. The unit operates between 0 °C and 35 °C with 5 to 95 percent relative humidity and accepts 100 to 240 VAC power. Drive bays accept 3.5 inch SATA hard drives or 2.5 inch SATA SSDs only.

Highlights

  • AMD Ryzen V1500B four-core processor powers demanding workloads
  • 32GB DDR4 ECC memory supports virtualisation and multitasking
  • 80TB raw capacity with four 20TB Synology Plus drives
  • Four 1GbE ports enable link aggregation and failover
  • PCIe Gen3 slot allows 10GbE or 25GbE upgrade

Specifications

BrandSynology
ModelRS826+
Port RJ-454 x 10/100/1000M
Port USB2 x USB 3.2 Gen 1 Ports
Form Factor4-Bay
ProcessorAMD Ryzen
Installed Memory32GB
Included HDD Capacity80TB (4 x 20TB)
ManagementWeb-Based, DHCP Client
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Temperature0°C - 35 °C
Humidity5-95% R.H
Dimensions44 mm × 480 mm × 492.6 mm
Weight6.4 kg
Package ContentsMain Unit × 1
Accessory Pack × 1
AC Power Cord × 1
All Configuration Items

Questions about this item

How much power does the RS826+ draw when running continuously in a 1U rack?

The unit operates on 100-240 VAC at 50/60 Hz and is rated for an ambient temperature range of 0°C to 35°C during continuous operation.

Which drives and memory are already installed so the NAS works out of the box?

It ships with four 20TB Synology Plus drives totalling 80TB and 32GB of DDR4 ECC memory pre-installed in the four drive bays.

Will my existing 1GbE switches and Cat5e cabling work with the four built-in RJ-45 ports?

Yes, the four 10/100/1000M ports are compatible with standard 1GbE switches and Cat5e or better cabling, and support Link Aggregation for load balancing.
