Black 1U rackmount NAS with four front drive bays, status LEDs and rear 25GbE SFP28 ports

Synology Inc.

Synology RS826+ Ryzen V1500B 4-Bay Rackmount NAS 16GB 24TB 25GbE

SKU CH-F96R-9M63J

A compact 1U rackmount NAS with four bays holding 24 TB, a Ryzen V1500B processor, 16 GB DDR4 memory and a 25 GbE adapter

  • Port RJ-454 x 10/100/1000M 2 x 25GbE SFP28
  • Port USB2 x USB 3.2 Gen 1 Ports
  • Form Factor4-Bay
  • ProcessorAMD Ryzen
  • Installed Memory16GB
  • Included HDD Capacity24TB (4 x 6TB)
  • Ready-to-deploy system with 24 TB storage included
  • AMD Ryzen V1500B four-core processor handles demanding workloads
  • 16 GB DDR4 ECC memory protects data integrity
  • Dual 25 GbE SFP28 ports deliver high-speed connectivity
  • Four 1 GbE RJ-45 ports support link aggregation

Synology RS826+ 4-Bay Rackmount NAS

The Synology RS826+ is a 1U rackmount network-attached storage server powered by a 2.2 GHz AMD Ryzen V1500B four-core processor. It arrives fully assembled with 16GB of DDR4 ECC memory, a dual-port 25GbE SFP28 adapter, and four 6TB Synology Plus drives installed for 24TB of raw capacity. Four drive bays accept 3.5-inch or 2.5-inch SATA drives, and four 1GbE RJ-45 ports support link aggregation.

Suits small offices needing dense 25GbE connectivity

This unit fits businesses that want a pre-configured, space-saving storage node with high-speed 25GbE uplinks and ECC memory for data integrity. The included drives and adapter are validated by the assembler for immediate deployment. Organisations requiring more than four drive bays, a different drive capacity mix, or greater than 32GB of memory will need a different platform.

Four-bay chassis with 25GbE SFP28 adapter included

The defining specification is the combination of four SATA drive bays and the factory-installed dual-port 25GbE SFP28 adapter, which sets the storage density ceiling and the peak network throughput in a single 1U form factor. Memory can be expanded to 32GB, but the bay count and supplied 24TB drive set are fixed.

Highlights

  • Ready-to-deploy system with 24 TB storage included
  • AMD Ryzen V1500B four-core processor handles demanding workloads
  • 16 GB DDR4 ECC memory protects data integrity
  • Dual 25 GbE SFP28 ports deliver high-speed connectivity
  • Four 1 GbE RJ-45 ports support link aggregation

Specifications

BrandSynology
ModelRS826+
Port RJ-454 x 10/100/1000M
2 x 25GbE SFP28
Port USB2 x USB 3.2 Gen 1 Ports
Form Factor4-Bay
ProcessorAMD Ryzen
Installed Memory16GB
Included HDD Capacity24TB (4 x 6TB)
ManagementWeb-Based, DHCP Client
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Temperature0°C - 35 °C
Humidity5-95% R.H
Dimensions44 mm × 480 mm × 492.6 mm
Weight6.4 kg
Package ContentsMain Unit × 1
Accessory Pack × 1
AC Power Cord × 1
All Configuration Items

Questions about this item

How much power does the RS826+ draw when the four 6 TB drives and 25 GbE adapter run continuously?

The unit accepts 100-240 VAC at 50/60 Hz; exact sustained draw depends on workload and drive activity.

Which drives or media must I already own to start using the four bays?

All four 6 TB Synology Plus SATA drives are already installed, so no additional drives are required.

Will the four integrated 1 GbE RJ-45 ports and the installed 25 GbE SFP28 adapter work with my existing 1 GbE switch?

Yes, the 1 GbE ports connect directly; the 25 GbE ports need a compatible SFP28 transceiver and a switch that supports 25 GbE or 10 GbE.
