Green circuit board with gold edge connector and black controller chip

Team Group

Team Group MP33 512GB M.2 2280 PCIe 3.0 x4 NVMe 1.3 internal SSD TM8FP6512G0C101

SKU CH-MCWB-TNX1R MPN TM8FP6512G0C101

A 512 GB M.2 2280 PCIe 3.0 x4 NVMe 1.3 SSD with 3D NAND, DRAM-less HMB caching, 1700 MB/s read, 1400 MB/s write, 220000 IOPS random read, 200000 IOPS random write, 120 TBW and 1500000-hour MTBF

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity512GB
  • Memory Components3D NAND
  • InterfacePCIe 3.0 x4 with NVMe 1.3

Options 512GB MP33

  • Fast boot and load times with up to 1700 MB/s sequential read
  • Smooth multitasking from up to 220,000 random read IOPS
  • 512 GB capacity on 3D NAND stores large libraries
  • 120 TBW and 1,500,000-hour MTBF back long-term reliability
  • M.2 2280 PCIe 3.0 x4 NVMe 1.3 fits desktops and laptops

Team Group MP33 512GB NVMe SSD

The Team Group MP33 is a 512GB internal solid-state drive built for consumer desktops and notebooks. It uses an M.2 2280 form factor with a PCIe 3.0 x4 interface and the NVMe 1.3 protocol. 3D NAND flash provides the storage medium without a discrete DRAM cache, relying on host memory buffer support.

PCIe 3.0 x4 NVMe 1.3 interface

The single specification that determines compatibility is the PCIe 3.0 x4 connection with NVMe 1.3. The drive fits any M.2 2280 slot wired for PCIe, which covers most Intel and AMD platforms from recent years. Systems limited to SATA or PCIe 2.0 will not recognise the drive at its rated speeds.

512GB capacity with 120TB TBW

Sequential reads reach 1700 MBps and writes reach 1400 MBps, while random 4KB performance hits 220,000 read IOPS and 200,000 write IOPS. The 120TB terabytes-written rating and 1.5 million hour MTBF give ample headroom for daily workloads, gaming, and moderate content creation. Sustained heavy write workloads will eventually saturate the SLC cache and reduce throughput.

Highlights

  • Fast boot and load times with up to 1700 MB/s sequential read
  • Smooth multitasking from up to 220,000 random read IOPS
  • 512 GB capacity on 3D NAND stores large libraries
  • 120 TBW and 1,500,000-hour MTBF back long-term reliability
  • M.2 2280 PCIe 3.0 x4 NVMe 1.3 fits desktops and laptops

Specifications

BrandTeam Group
SeriesMP33
ModelTM8FP6512G0C101
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity512GB
Memory Components3D NAND
InterfacePCIe 3.0 x4 with NVMe 1.3
ProtocolNVMe 1.3
CacheNo DRAM (HMB)
Max Sequential ReadUp to 1700 MBps
Max Sequential WriteUp to 1400 MBps
4KB Random ReadUp to 220,000 IOPS
4KB Random WriteUp to 200,000 IOPS
Terabytes Written (TBW)120TB
MTBF1,500,000 hours
FeaturesUsing new generation of 3D flash memory: Capacity, performance, and durability are greatly improved
PCI-e interface - Supports latest NVMe 1.3 protocol
M.2 2280 specification: Supports the next-generation platforms of Intel and AMD. Suitable for both desktop and notebook
Supports SLC Caching technology. Greatly enhance computing performance
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Operating HumidityRH 90% under 40 celsius degree
Max Shock Resistance1,500G / 0.5 ms
Max Vibration Resistance80-2,000 Hz / 20G
Height3.80mm
Width22.00mm
Depth80.00mm
Weight6.00g
Shipping weight0.01 kg
Package size123 × 89 × 8 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What real-world speed can I expect from the 1700 MBps sequential read figure once the MP33 is installed?

The 1700 MBps sequential read is the drive's peak rating; actual throughput depends on your motherboard's PCIe 3.0 x4 implementation, workload and thermal conditions.

How does the PCIe 3.0 x4 NVMe 1.3 interface limit performance in practice?

PCIe 3.0 x4 caps theoretical bandwidth near 4 GBps, so the MP33's 1700/1400 MBps sequential speeds run well within the link limit; NVMe 1.3 adds command-set refinements without raising the ceiling.

Will the M.2 2280 form factor fit both my laptop and desktop motherboard?

The 2280 length (80 mm) is the standard M.2 size; it fits any M-keyed slot wired for PCIe on Intel or AMD platforms, desktop or notebook, provided the board has physical clearance for a single-sided module.
