Green circuit board with black graphene label, M.2 2280 form factor

Team Group

Team Group MP44 TM8FPW004T0C101 4TB M.2 2280 internal SSD

SKU CH-FW20-AH3AV MPN TM8FPW004T0C101

A 4TB M.2 2280 drive with PCIe 4.0 speeds up to 7400/6900 MB/s and a graphene heat label

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity4TB
  • Memory Components3D NAND
  • InterfacePCIe 4.0 x4 with NVMe

Options 4TB

  • 4 TB capacity stores documents, pictures, videos and games
  • Up to 7400 MB/s sequential read speeds up data access
  • Graphene heat-dissipating label improves motherboard heatsink cooling
  • 2000 TBW endurance rating supports heavy write workloads
  • S.M.A.R.T. monitoring tracks drive health and status

High-capacity 4TB NVMe drive

This internal SSD uses the PCIe 4.0 x4 interface with NVMe to deliver up to 7400 MB/s sequential read and 6900 MB/s sequential write. The 4TB capacity stores large game libraries, video projects and system images in a single M.2 2280 module. It suits desktop, laptop, NUC and NAS platforms that support the form factor and protocol.

Sustained load with graphene label

The drive employs a sub-1mm graphene label that works alongside a motherboard heatsink to dissipate heat during prolonged transfers. Without a separate DRAM cache, the controller relies on Host Memory Buffer to maintain throughput. Rated endurance of 2000 TBW and an MTBF of 1600000 hours indicate durability for continuous workloads within the 0 °C to 70 °C operating range.

Verify slot and cooling before ordering

Confirm the host provides an M.2 2280 slot wired for PCIe 4.0 x4 and NVMe; older keying or PCIe 3.0 will limit speed. Ensure the onboard heatsink makes contact with the graphene label, as the drive has no integrated thermal solution. Check that the platform BIOS recognises 4TB NVMe volumes and that the OS supports the capacity.

Highlights

  • 4 TB capacity stores documents, pictures, videos and games
  • Up to 7400 MB/s sequential read speeds up data access
  • Graphene heat-dissipating label improves motherboard heatsink cooling
  • 2000 TBW endurance rating supports heavy write workloads
  • S.M.A.R.T. monitoring tracks drive health and status

Specifications

BrandTeam Group
SeriesMP44
ModelTM8FPW004T0C101
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity4TB
Memory Components3D NAND
InterfacePCIe 4.0 x4 with NVMe
ProtocolNVMe
CacheNo DRAM (HMB)
Max Sequential ReadUp to 7400 MBps
Max Sequential WriteUp to 6900 MBps
4KB Random ReadUp to 650,000 IOPS
4KB Random WriteUp to 660,000 IOPS
Terabytes Written (TBW)2000TB
MTBF1,600,000 hours
FeaturesMP44 M.2 PCIe 4.0 SSD adopts the PCIe Gen4x4 interface. It features read/write speeds of up to 7,400/7,000 MB/s and a maximum storage capacity of 8TB. It is equipped with TEAMGROUP’s exclusive patented heat dissipating graphene label less than 1mm thick, which is also compatible with the onboard M.2 heat sink for superior heat dissipation performance to that of the native motherboard heat sink alone. It is undoubtedly the best enhancement to native heat sinks.
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Operating HumidityRH 90% under 40 celsius degree
Max Shock Resistance1,500G / 0.5 ms
Max Vibration Resistance80~2,000 Hz / 20G
Height3.70mm
Width22.00mm
Depth80.00mm
Weight7.00g
Shipping weight0.03 kg
Package size124 × 89 × 18 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will this 4TB M.2 2280 drive fit in a laptop with a single-sided M.2 slot?

The drive uses the M.2 2280 form factor and is less than 1mm thick, so it fits standard single-sided slots without mechanical interference.

Does the drive need a motherboard heatsink for sustained PCIe 4.0 speeds?

A graphene label is included to enhance the onboard M.2 heatsink; pairing it with the motherboard heatsink improves thermal performance during heavy workloads.

What does the 2000TBW rating mean for daily use?

The 2000 terabytes written endurance rating indicates the total data you can write over the drive’s warranted lifespan, suitable for heavy consumer workloads.
