Green graphene-coated M.2 2280 SSD with gold edge connector

Team Group

Team Group TM8FPK002T0C101 2TB M.2 2280 PCIe 4.0 x4 NVMe 1.4 internal SSD

SKU CH-C2Z5-2F3YV MPN TM8FPK002T0C101

2 TB PCIe 4.0 x4 NVMe 1.4 M.2 2280 SSD with graphene heat-dissipating label, up to 4800 MB/s read and 4400 MB/s write, 640 TBW

  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity2TB
  • InterfacePCIe 4.0 x4 with NVMe 1.4
  • ProtocolNVMe 1.4
  • CacheNo DRAM (HMB)

Options 2TB

  • Graphene label cuts heat while staying under 1 mm thick
  • PCIe 4.0 x4 NVMe 1.4 delivers 4800 MB/s reads
  • SLC cache drives 4400 MB/s writes and 550000 IOPS
  • 640 TBW plus 1500000 hour MTBF for long life
  • TRIM and LDPC keep data accurate under heavy loads

Capacity and interface

The Team Group MP44L TM8FPK002T0C101 is a 2TB M.2 2280 internal SSD that uses a PCIe 4.0 x4 interface with NVMe 1.4. It is built for consumer workloads such as gaming, content creation and everyday computing. The drive operates without a dedicated DRAM cache and instead relies on Host Memory Buffer technology.

Sustained performance

Sequential reads reach up to 4800 MBps while sequential writes reach up to 4400 MBps. Random 4KB reads hit 525,000 IOPS and random 4KB writes hit 550,000 IOPS. SLC caching helps maintain high throughput during extended write sessions. The drive is rated for 640TB written and a mean time between failures of 1,500,000 hours.

Thermals and power

A graphene-coated label works with the motherboard M.2 heatsink to double heat dissipation while staying under 1 mm thick. The controller is specified to run from 0 °C to 70 °C and can be stored from -40 °C to 85 °C. Operating humidity is rated at 90 % at 40 °C and shock resistance reaches 1,500 G for 0.5 ms.

Highlights

  • Graphene label cuts heat while staying under 1 mm thick
  • PCIe 4.0 x4 NVMe 1.4 delivers 4800 MB/s reads
  • SLC cache drives 4400 MB/s writes and 550000 IOPS
  • 640 TBW plus 1500000 hour MTBF for long life
  • TRIM and LDPC keep data accurate under heavy loads

Specifications

BrandTeam Group
SeriesMP44L
ModelTM8FPK002T0C101
Used ForConsumer
Form FactorM.2 2280
Capacity2TB
InterfacePCIe 4.0 x4 with NVMe 1.4
ProtocolNVMe 1.4
CacheNo DRAM (HMB)
Max Sequential ReadUp to 4800 MBps
Max Sequential WriteUp to 4400 MBps
4KB Random ReadUp to 525,000 IOPS
4KB Random WriteUp to 550,000 IOPS
Terabytes Written (TBW)640TB
MTBF1,500,000 hours
FeaturesTEAMGROUP MP44L M.2 PCIe SSD adopts the PCIe Gen4x4 interface. Compared with the PCIe Gen3, the performance is more than doubled. The read/write speeds reach up to 5,000 / 4,500MB/s, drastically improving work efficiency. It is the first product to incorporate a heat sink label using a unique graphene coating on aluminum foil to further upgrade heat dissipation performance. It supports the S.M.A.R.T. monitoring software, Windows TRIM optimization option, and LDPC technology simultaneously.
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Operating HumidityRH 90% under 40°C (operational)
Max Shock Resistance1,500G/0.5ms
Max Vibration Resistance80Hz~2,000Hz/20G
Height2.25mm
Width22mm
Depth80mm
Weight7g
Shipping weight0.02 kg
Package size127 × 93 × 15 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the graphene label and onboard heatsink keep the drive cool during sustained 4800 MBps reads?

The graphene-coated label works with the motherboard M.2 heatsink to double heat dissipation, keeping the controller within its 0 °C to 70 °C operating range during continuous PCIe 4.0 x4 workloads.

Will my motherboard need an M.2 slot wired for PCIe 4.0 x4 and NVMe 1.4 to run this 2 TB MP44L?

Yes, the drive requires an M.2 2280 slot that supports PCIe 4.0 x4 and NVMe 1.4; it will fall back to PCIe 3.0 speeds if the slot is only Gen3.

Can I keep my older PCIe 3.0 M.2 drive alongside this MP44L without bandwidth conflicts?

Each M.2 slot connects to its own PCIe lanes, so the MP44L running at Gen4 x4 will not share bandwidth with a Gen3 drive in a separate slot.
