Thermaltake

Thermaltake Toughpower GF A3 1050W TT Premium Edition power supply

SKU CH-DGTF-Q7YSD

Fully modular 1050 W ATX 3.0 unit with native 12VHPWR connector, 80 PLUS Gold efficiency and Japanese capacitors

  • ColorBlack
  • TypeATX 3.0 Compatible
  • Fans1 x 120 mm
  • PFCActive
  • ModularFull Modular
  • Power Good Signal100-250 msec
  • 80 PLUS Gold efficiency cuts running costs
  • 1050W output powers demanding builds
  • ATX 3.0 design handles 200% power excursions
  • Native 12VHPWR cable delivers up to 300W to PCIe 5.0 GPUs
  • Fully modular cabling reduces clutter and improves airflow

1050W ATX 3.0 power supply for modern PCs

This fully modular unit delivers 1050W total output and meets Intel ATX 3.0 specifications. It includes a native 16-pin 12VHPWR connector for PCIe 5.0 graphics cards. The design targets builders who want a single-cable GPU connection and 80 PLUS Gold efficiency. Builders needing more than 1050W should choose a higher-wattage model.

Native 12VHPWR connector with 300W delivery

The single specification that decides fit is the 12VHPWR connector rated for up to 300W on the PCIe 5.0 cable. This allows direct power to compatible graphics cards without adapters. If your GPU uses only traditional 8-pin connectors, this specific feature goes unused. Buyers with older cards that lack a 12VHPWR socket will not benefit from the native cable.

1050W capacity handles high-end single-GPU systems

At 1050W the unit comfortably powers a flagship GPU and a high-performance CPU together with headroom for transient spikes up to 200 percent excursion. The 80 PLUS Gold rating ensures efficient operation at typical loads. Systems planning dual flagship GPUs or extreme overclocking beyond 1050W will exceed this unit's continuous rating.

Highlights

  • 80 PLUS Gold efficiency cuts running costs
  • 1050W output powers demanding builds
  • ATX 3.0 design handles 200% power excursions
  • Native 12VHPWR cable delivers up to 300W to PCIe 5.0 GPUs
  • Fully modular cabling reduces clutter and improves airflow

Specifications

BrandThermaltake
SeriesTOUGHPOWER GF A3
ColorBlack
TypeATX 3.0 Compatible
Fans1 x 120 mm
PFCActive
ModularFull Modular
Power Good Signal100-250 msec
Hold-up Time> 17msec
Energy-Efficient80 PLUS GOLD Certified
Over Voltage ProtectionYes
Input Voltage100 - 240 V
Input Frequency Range50Hz - 60Hz
Input Current10A Max.
MTBF>100,000 Hours
ApprovalsCE/FCC/UKCA/ICES/LVD/TUV/cTUVus/CB/CCC/BSMI
Dimensions150mm(W)x86mm(H)x140mm(D)
Weight1.63kg
+3.3V Max. Current20A
+5V Max. Current20A
+12V1 Max. Current62.5A
-12V Max. Current3A
+5VSB Max. Current0.3A
Main Connector24 Pin
PCI-Express Connector4 x 8-Pin (6+2) PCI-E connectors,
1 x 16-Pin (12+4) PCI-E connector
SATA Power Connector8
Floppy Connector1
Peripheral Connector4
Fans Total Quantity1
Top Fans Size120mm
Short Circuit ProtectionYes
Under Voltage ProtectionYes
Over Current ProtectionYes
Over Power ProtectionYes
Over Temperature ProtectionYes

Questions about this item

What does the 1050W rating mean for a system with a high-end graphics card?

The unit can deliver up to 1050W total continuous power, with the native 16-pin 12VHPWR cable rated to supply up to 300W to a single PCIe 5.0 graphics card, leaving the remaining capacity for CPU, drives and peripherals.

How does the ATX 3.0 design affect power delivery limits?

The ATX 3.0 platform supports up to 200% power excursion for short bursts and guarantees 60% efficiency at low loads, while the 12VHPWR connector is specified for 300W continuous delivery to the GPU.

Will this 150mm wide by 140mm deep unit fit in a standard ATX case?

The housing measures 150mm wide, 86mm high and 140mm deep, matching the standard ATX power supply envelope, so it fits any case designed for a regular ATX unit.
