Thermaltake
Thermaltake Toughpower PF1 750W 80+ Platinum Full Modular Power Supply PS-TPD-0750FNFAPU-1
A 750W fully modular ATX power supply with 80 Plus Platinum efficiency, a 120mm hydraulic-bearing fan, single +12V rail, compact 140mm depth and Japanese 105°C capacitors
- TypeATX12V / EPS12V
- Maximum Power750 W
- Fans120mm Hydraulic Bearing Fan
- PFCActive
- Main Connector24Pin
- +12V RailsSingle
- Platinum efficiency up to 92% cuts running costs
- Compact 140mm depth frees space for cable routing
- Fully modular flat black cables simplify build tidiness
- Japanese 105°C capacitors ensure long-term reliability
- Hydraulic bearing fan runs ultra quiet with smart zero mode
Thermaltake Toughpower PF1 750W Platinum PSU
This 750W ATX12V unit delivers 80 PLUS Platinum efficiency up to 92%. A compact 140mm depth and single-sided SMD layout keep cable routing tidy. Fully modular flat black cables and 100% Japanese 105°C capacitors ensure clean builds and long-term reliability.
Suits builders needing Platinum efficiency
The 140mm length fits tight chassis where longer units block drive bays or radiators. Four 6+2-pin PCIe connectors handle dual-GPU setups, while nine SATA plugs serve large storage arrays. Systems requiring more than 750W should consider higher-capacity models.
140mm depth decides fit in compact builds
At 140mm deep the PSU leaves room behind the motherboard tray for cable bends and airflow. Verify your case specification accepts this length before ordering. The single +12V rail and DC-to-DC design provide stable power once installed.
Highlights
- Platinum efficiency up to 92% cuts running costs
- Compact 140mm depth frees space for cable routing
- Fully modular flat black cables simplify build tidiness
- Japanese 105°C capacitors ensure long-term reliability
- Hydraulic bearing fan runs ultra quiet with smart zero mode
Specifications
| Brand | Thermaltake |
|---|---|
| Series | Toughpower PF1 750W |
| Model | PS-TPD-0750FNFAPU-1 |
| Type | ATX12V / EPS12V |
| Maximum Power | 750 W |
| Fans | 120mm Hydraulic Bearing Fan |
| PFC | Active |
| Main Connector | 24Pin |
| +12V Rails | Single |
| PCI-Express Connector | 4 x 6+2-Pin |
| SATA Power Connector | 9 |
| Max PSU Length | 140 mm |
| Modular | Full Modular |
| Power Good Signal | 100-500ms |
| Hold-up Time | > 16msec at 100% of full load |
| Energy-Efficient | 80 PLUS PLATINUM Certified |
| PSU Noise Level | Cybenetics A- |
| Protection | OCP, OVP, UVP, OPP, SCP, OTP |
| Input Voltage | 100 - 240 V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 10A |
| Output | +3.3V@20A, +5V@20A, +12V@62A, [email protected] , [email protected] |
| MTBF | >120,000 Hours |
| Approvals | CE / UL / TÜV / FCC / BSMI / CCC / EAC certifications |
| Connectors | 1 xMain Power Connector (24pin) 2 x ATX 12V / EPS 12V (4+4pin) 9 x SATA (5pin) 4 x PCI-E (6+2pin) 4 x Peripheral (4pin) 1 x Floppy |
| Features | 80 Plus Platinum Certified Compact 140mm Depth Design Fully modular low-profile flat black cables 100% high quality Japanese 105°C/221°F capacitors High amperage single +12V rail & DC to DC design <30mV low ripple noise design Extremely strict voltage regulation <+/-2% Intel C6/C7 States & ERP ready Warranty: 10 Years |
| Dimensions | 3.39" x 5.91" x 5.51" |
| Shipping weight | 2.77 kg |
| Package size | 320 × 221 × 135 mm |
Questions about this item
What case clearance do I need for the 140 mm depth of this PSU?
The unit is 140 mm deep, so your case must provide at least that much clear space behind the motherboard tray for the power supply to fit.
Will the single +12V rail and DC-to-DC design work with older components that expect multi-rail layouts?
Yes, the single high-amperage +12V rail with DC-to-DC conversion delivers stable power to legacy parts without the cross-load issues sometimes seen on multi-rail units.
How can I confirm the fan is running only when needed after I build the system?
The Smart Zero Fan mode keeps the 120 mm hydraulic-bearing fan off at low loads; you will hear it spin up only when internal temperature or load crosses the built-in threshold.
