White 95mm fan on vertical copper heatsink, 66mm tall

TITAN Technology Limited

TITAN Technology Limited TTC-NA02TZ/RPW/CU30 95mm Z-AXIS Copper CPU Cooler

SKU CH-0H1Y-42DT7 MPN TTC-NA02TZ/RPW/CU30

Copper heatsink with 95 mm Z-AXIS fan, 900-2600 RPM, <33 dBA, fits Intel LGA 1150/1151/1155/1156 sockets

  • ColorWhite
  • TypeFan & Heatsinks
  • Fan Size95mm
  • CPU Socket CompatibilityIntel LGA 1150 / Intel LGA 1151 / Intel LGA 1155 / Intel LGA
  • Bearing TypeZ-AXIS
  • RPM900-2600 RPM
  • Low-noise cooling with
  • Wide speed range from 900 to 2600 RPM
  • Strong airflow up to 47.62 CFM
  • Copper heatsink for efficient heat transfer
  • Fits Intel LGA 1150, 1151, 1155, 1156 sockets

Targeted Socket Compatibility

This copper air cooler fits Intel LGA 1150, 1151, 1155 and 1156 sockets. A 95 mm Z-AXIS fan delivers 16.5 to 47.62 CFM across a 900 to 2600 RPM range while staying below 33 dBA. The vertical fin stack tops out at 66 mm tall, suited to compact builds.

Buyers Outside Supported Platforms

Systems using AMD sockets or newer Intel platforms beyond LGA 1151 are not supported by the supplied mounting kit. The single 4-pin connector also limits control options on boards that expect dual-fan headers or additional sensor leads.

Critical Clearance Limit

Maximum cooler height is 66 mm, so the chassis CPU cooler clearance must meet or exceed that figure. Any case with a lower limit will prevent installation regardless of socket match.

Highlights

  • Low-noise cooling with
  • Wide speed range from 900 to 2600 RPM
  • Strong airflow up to 47.62 CFM
  • Copper heatsink for efficient heat transfer
  • Fits Intel LGA 1150, 1151, 1155, 1156 sockets

Specifications

BrandTitan
ModelTTC-NA02TZ/RPW/CU30
ColorWhite
TypeFan & Heatsinks
Fan Size95mm
CPU Socket CompatibilityIntel LGA 1150 / Intel LGA 1151 / Intel LGA 1155 / Intel LGA 1156
Bearing TypeZ-AXIS
RPM900-2600 RPM
Air Flow16.5-47.62 CFM
Noise Level<33 dBA
Power Connector4 Pin
Heatsink MaterialCopper
Fan Mounting Types to HeatsinkVertical
Max CPU Cooler Height66 mm
Fan Dimensions95 x 95 x 25 mm
Shipping weight0.48 kg
Package size109 × 107 × 102 mm

Questions about this item

Will the Z-AXIS bearing in the 95mm fan need lubrication or replacement over time?

The Z-AXIS bearing is a sealed design rated for continuous operation without user lubrication or scheduled replacement.

At sustained 2600 RPM, does airflow or noise hit the limit first?

Maximum airflow reaches 47.62 CFM at 2600 RPM while noise stays below 33 dBA, so thermal capacity is the limiting factor.

How loud and hot does the cooler get when running at full speed all day?

At full speed the fan produces up to 47.62 CFM while staying under 33 dBA, and the copper heatsink dissipates heat without raising case temperature excessively.
