Silver horizontal 2U rack PDU with 24 front outlets and one twist-lock outlet, dual input cords, digital meter and network port

Tripp Lite

Tripp Lite PDUMNH30AT2 25-Outlet Monitored PDU 30A 120V 2U Horizontal

SKU CH-NPXQ-BXJKP MPN PDUMNH30AT2

A monitored 2U horizontal PDU with 25 outlets, dual 10 ft 30 A inputs and real-time remote metering for 120 V rack equipment

  • TypeMonitored
  • Rack Size2U
  • StyleHorizontal
  • Package IncludesPDUMNH30AT2 2.9kW Single-Phase ATS/Monitored PDU Configurati
  • Input Voltage120V
  • Maximum Input Current30A
  • Real-time remote monitoring via built-in network interface
  • Auto-transfer switching provides redundant A/B power for single-corded devices
  • 24 NEMA 5-15/20R and 1 NEMA L5-30R outlets distribute 120V AC power
  • Dual 10 ft NEMA L5-30P input cords connect to separate power sources
  • 2U horizontal rack-mountable design with TAA compliance for GSA Schedule purchases

25-Outlet Monitored PDU for 30A 120V Racks

The Tripp Lite PDUMNH30AT2 is a 2U horizontal power distribution unit built for monitored environments that need real-time current metering and remote load balancing. It accepts dual NEMA L5-30P inputs and provides 24 NEMA 5-15/20R outlets plus one NEMA L5-30R outlet for connected equipment. Network IT rooms and small computer installations use it to prevent circuit overloads through continuous voltage, frequency and load monitoring. Its auto-transfer switching enables redundant A/B power for single-corded devices.

Thermals Noise and Power Draw

The unit operates at a maximum input current of 30A and delivers up to 2.9kW of single-phase 120V power across two 20A output breakers, each protecting twelve 5-15/20R outlets. Dual 10 ft input cords connect to separate primary and secondary mains circuits to maintain availability during source failures. A rear grounding lug provides TVSS grounding for surge protection. The horizontal 2U form factor fits standard rack enclosures without additional airflow requirements.

Bundled Accessories and Software

The package includes a configuration cable and a USB-A to USB Micro-B cable for initial setup and local management access. Rack-mounting hardware, four cord retention brackets and twenty-four cable ties support secure horizontal installation and cable organisation. An owner's manual documents the built-in HTML5-based LX Platform interface that enables 24/7 remote monitoring through a standard network connection. TAA compliance allows the PDU to qualify for GSA Schedule procurement.

Highlights

  • Real-time remote monitoring via built-in network interface
  • Auto-transfer switching provides redundant A/B power for single-corded devices
  • 24 NEMA 5-15/20R and 1 NEMA L5-30R outlets distribute 120V AC power
  • Dual 10 ft NEMA L5-30P input cords connect to separate power sources
  • 2U horizontal rack-mountable design with TAA compliance for GSA Schedule purchases

Specifications

BrandTripp Lite
ModelPDUMNH30AT2
TypeMonitored
Rack Size2U
StyleHorizontal
Package IncludesPDUMNH30AT2 2.9kW Single-Phase ATS/Monitored PDU
Configuration cable, USB-A to USB Micro-B
Rack-mounting hardware
4 x Cord retention brackets
24 x Cable ties
Owner's manual
Input Voltage120V
Maximum Input Current30A
Cord Length10 ft
Overload Protection2x 20A output breakers protect 12 5-15/20R outlets each
FeaturesTVSS Grounding: Rear grounding lug
High Availability PDU Features: Auto-Transfer Switching
Dimensions3.41" x 17.32" x 11.89"
Weight13.71 lbs.
Shipping weight8.17 kg
Package size508 × 432 × 203 mm

Questions about this item

How do I install the PDUMNH30AT2 in a rack, and which step is often missed?

Mount the 2U horizontal unit using the included rack-mounting hardware, connect the dual 10 ft NEMA L5-30P cords to separate 30A 120V circuits, then attach the 4 cord retention brackets and 24 cable ties — the step most often missed is securing both input cords to independent sources so the auto-transfer switch can function.

What maintenance or replacement will the PDUMNH30AT2 need over time?

The two 20A output breakers protecting each bank of 12 NEMA 5-15/20R outlets are the only user-serviceable protective devices; if a breaker trips repeatedly, reset it once, then replace the breaker module if nuisance tripping continues.

What limit appears first when the PDUMNH30AT2 runs near capacity for long periods?

The 30A input rating and the dual 20A branch breakers cap continuous draw at 2.9 kW; sustained loads above 24A per input will trip the 20A breakers before the 30A inlet becomes the bottleneck.
