Green printed circuit board with black controller and silver label, M.2 2280 stick form factor

Western Digital

Western Digital Blue SN550 WDS100T2B0C 1TB NVMe M.2 2280 internal SSD

SKU CH-QYQ6-EQM3Z MPN WDS100T2B0C

A 1 TB NVMe internal SSD with 2400 MBps read and 1950 MBps write speeds in M.2 2280 form factor

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4

Options 1TB

  • Boost system responsiveness with NVMe read speeds up to 2400 MB/s
  • Write large files quickly using sequential write performance up to 1950 MB/s
  • Handle heavy multitasking with random read IOPS up to 345000
  • Extend drive lifespan with 600 TBW endurance rating
  • Fit compact builds using single-sided M.2 2280 form factor

1TB NVMe M.2 2280 for consumers

The Western Digital Blue SN550 WDS100T2B0C is a 1TB internal solid state drive built for consumer PCs. It uses a single-sided M.2 2280 form factor with 3D NAND memory and a PCI-Express 3.0 x4 interface. The drive is designed to boost system responsiveness for everyday workloads. Its Western Digital controller and firmware are tuned for balanced performance and low power draw.

PCI-Express 3.0 x4 interface limits

This SSD connects through a PCI-Express 3.0 x4 link, which caps its maximum theoretical bandwidth. Sequential reads reach up to 2400 MBps and writes up to 1950 MBps within that ceiling. Random performance delivers up to 345000 IOPS for reads and 385000 IOPS for writes. The drive operates between 0°C and 70°C and idles at 30 mW in low-power state.

600TB endurance rating

The drive carries a terabytes written rating of 600TB, which is the single figure that determines whether it suits your write workload. A mean time to failure of 1.7M hours supports long-term reliability. Active power consumption peaks at 3.5W, while sleep state drops to 5 mW. These numbers define the practical service life for consumer use.

Highlights

  • Boost system responsiveness with NVMe read speeds up to 2400 MB/s
  • Write large files quickly using sequential write performance up to 1950 MB/s
  • Handle heavy multitasking with random read IOPS up to 345000
  • Extend drive lifespan with 600 TBW endurance rating
  • Fit compact builds using single-sided M.2 2280 form factor

Specifications

BrandWestern Digital
SeriesBlue SN550 NVMe
ModelWDS100T2B0C
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4
Max Sequential ReadUp to 2400 MBps
Max Sequential WriteUp to 1950 MBps
4KB Random ReadUp to 345,000 IOPS
4KB Random WriteUp to 385,000 IOPS
Terabytes Written (TBW)600TB
MTTF1.7M hours
FeaturesThe right storage for your next PC
NVMe goes mainstream with a powerful, cost-effective storage solution that adds to the reliability of an SSD.
Boost your performance
Get breakneck sequential read speeds up to 2,400 MB/s to improve your productivity no matter what you're doing or creating.
Think small
Build powerful small-form factor PCs with a slim single-sided M.2 2280 PCIe Gen3 x4 NVMe SSD.
Do more with less
Scalable NVMe hardware, accelerated architecture for high performance and low power draw.
Do more, faster
Western Digital-designed controller and firmware paired with our lat
Power Consumption (Idle)PS3 (Low Power): 30 mW
PS4 (Sleep): 5 mW
Power Consumption (Active)3.5W
Operating Temperature0°C ~ +70°C
Storage Temperature-55°C ~ +85°C
Max Shock Resistance1,500G @ 0.5 ms half sine
Max Vibration ResistanceOperating: 5 gRMS, 10-2000 Hz, 3 axes
Non-operating: 4.9 gRMS, 7-800 Hz, 3 axes
Height2.38mm
Width22.00mm
Depth80.00mm
Weight6.50g
Shipping weight0.05 kg
Package size130 × 100 × 3 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Which capacity of the Blue SN550 NVMe should I pick for a typical desktop build?

The 1 TB model gives you 600 TBW endurance and 1.7 M hours MTTF, enough headroom for heavy daily workloads without over-provisioning.

What does the 2 400 MB/s sequential read figure mean once the drive is installed in my PC?

Large files such as game assets or video projects will load at up to 2 400 MB/s, cutting wait times compared with SATA SSDs while staying within the PCIe 3.0 x4 link.

Does the PCIe 3.0 x4 interface cap real-world throughput?

The four-lane Gen 3 connection limits peak transfer to the rated 2 400 MB/s read and 1 950 MB/s write, so you will not see higher numbers even on a newer motherboard.
