Green rectangular motherboard with silver CPU socket, two black RAM slots, M.2 slot, three SATA ports, PCIe slots, rear I/O panel

WMtec

WMtec H310D server motherboard LGA 1151 DDR4 16GB M.2 SATA 3.0

SKU CH-JJ6B-4Q890

LGA 1151 server board with dual DDR4 slots up to 16 GB, M.2 NVMe, three SATA 3.0 ports and USB 3.1 in a 196 × 170 mm M-ATX form factor

  • CPU TypeDual Intel Xeon
  • Supports Intel 6th to 9th generation CPUs via LGA 1151 socket
  • Dual-channel DDR4 memory up to 16 GB across two slots
  • Onboard NVMe M.2 interface for high-speed storage
  • Three SATA 3.0 ports provide additional drive connectivity
  • M-ATX form factor measuring 196 mm by 170 mm

WMtec H310D LGA 1151 server motherboard

The WMtec H310D is an M-ATX server motherboard built around the Intel H310 chipset and an LGA 1151 socket. It provides two DDR4 memory slots with dual-channel support up to 16GB maximum capacity. Storage connections include three SATA 3.0 ports and one onboard NVMe M.2 interface, while expansion is handled by a PCI-E 16X slot and a PCI-E 1X slot. The board measures 196mm by 170mm and includes a Realtek LAN controller.

Suits builds needing a compact LGA 1151 platform

This motherboard fits small-form-factor servers or workstations that require an Intel H310-based board with M.2 NVMe support and multiple SATA drives. It is not suited for workloads that demand more than 16GB of system memory, for configurations needing additional PCIe lanes beyond the single 16X and 1X slots, or for environments that require integrated wireless networking or multiple Ethernet ports.

16GB DDR4 maximum capacity decides fit

The two DDR4 slots top out at 16GB total, so the memory ceiling is the single specification that determines whether this board can support your application. If the workload requires more memory, a different platform must be selected.

Highlights

  • Supports Intel 6th to 9th generation CPUs via LGA 1151 socket
  • Dual-channel DDR4 memory up to 16 GB across two slots
  • Onboard NVMe M.2 interface for high-speed storage
  • Three SATA 3.0 ports provide additional drive connectivity
  • M-ATX form factor measuring 196 mm by 170 mm

Specifications

CPU TypeDual Intel Xeon

Questions about this item

When will I need to add more DDR4 memory beyond the 16GB limit?

The board caps at 16 GB across its two DDR4 slots, so any workload that outgrows that ceiling will require a platform change rather than a simple module swap.

Which bottleneck appears first when the Realtek LAN runs at full throughput for hours?

Sustained wire-speed traffic will saturate the single Realtek controller before the PCIe 1× or 16× slots or the three SATA 3.0 ports become limiting factors.

How much heat and power should I budget for a 500 W supply running this M-ATX board all day?

A 500 W branded PSU is the minimum specified; the H310 chipset and LGA 1151 socket draw modest power, so sustained load stays well within that envelope with typical airflow.
