Black rectangular server motherboard with dual LGA 2011 sockets and two DDR4 slots

WMtec

WMtec X99-GT server motherboard LGA 2011-3/4 dual channel 2×32 GB DDR4

SKU CH-ZY6F-6XBA7

Dual-socket LGA 2011-3/4 board supports two Xeon CPUs and up to 64 GB of DDR4 memory in a compact 180 × 242 mm form factor

  • CPU TypeDual Intel Xeon
  • Dual-socket Xeon capacity with LGA 2011-3/4 support
  • 64 GB maximum DDR4 memory across two slots
  • Compatible with Xeon E5 2620 through 2680 v3/v4 series
  • Compact 180 x 242 mm black PCB form factor
  • Supports non-ECC, registered ECC and desktop DDR4 modules

Dual-Xeon server board with two DDR4 slots

The WMtec X99-GT is a server motherboard built around the X99 chipset and dual LGA 2011-3/4 sockets. It accepts two DDR4 modules up to 32 GB each, supporting non-ECC, registered ECC or standard desktop memory. The board measures 180 by 242 mm and ships in black PCB.

Suits dual-socket Xeon builds

This board fits builders assembling a dual-processor Xeon E5 v3 or v4 system where only two DIMM slots are required. It is not for buyers who need more than two memory modules, quad-channel bandwidth, additional expansion slots or onboard storage controllers beyond what the bare board provides.

Two DDR4 slots capped at 32 GB each

The single specification that decides fit is the pair of DDR4 sockets limited to 32 GB per slot. If the workload demands higher total memory capacity or more than two modules, this motherboard will not meet the requirement.

Highlights

  • Dual-socket Xeon capacity with LGA 2011-3/4 support
  • 64 GB maximum DDR4 memory across two slots
  • Compatible with Xeon E5 2620 through 2680 v3/v4 series
  • Compact 180 x 242 mm black PCB form factor
  • Supports non-ECC, registered ECC and desktop DDR4 modules

Specifications

CPU TypeDual Intel Xeon

Questions about this item

How much power does the X99-GT draw when both Xeon CPUs run at full load all day?

The board uses an LGA 2011-3/4 socket for dual Xeon processors; actual power draw depends on the specific E5 2620, 2630, 2640, 2650, 2660, 2670, 2678 or 2680 v3/v4 chips installed.

Which memory modules must I already have to reach the 2×32 GB DDR4 limit?

Two DDR4 DIMMs, non-ECC, registered ECC, standard ECC or desktop RAM, each up to 32 GB, are required to populate the two memory sockets.

Will my existing LGA 2011-3 Xeon E5 v3 coolers fit the X99-GT mounting holes?

The motherboard uses the LGA 2011-3/4 socket pattern, so coolers designed for that socket spacing will mount correctly.
