XPG SX8100 4TB M.2 2280 internal SSD, bare green circuit board with black memory chips, no heatsink

XPG

XPG SX8100 4TB M.2 2280 internal SSD

SKU CH-GRHV-1KV42

A 4TB M.2 2280 internal SSD using PCIe 3.0 x4 and 3D NAND for up to 3500 MB/s read and 3000 MB/s write with 2560 TBW endurance

  • Device TypeInternal (Desktop)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity4TB
  • Memory Components3D NAND
  • InterfacePCI-Express 3.0 x4

Options 4TB

  • 4TB
  • 2TB

Struck-through versions exist but are not stocked here.

  • Sequential reads up to 3500 MB/s for fast system responsiveness
  • Sequential writes up to 3000 MB/s for quick file saves and installs
  • Random reads up to 290000 IOPS for snappy multitasking and game loads
  • 2560 TB written endurance with 2000000 hour MTBF for long-term reliability
  • Low active power draw of 0.33 W and idle 0.14 W for cooler operation

XPG SX8100 4TB M.2 2280 SSD

The XPG SX8100 is a 4TB internal solid-state drive built for desktop PCs. It uses the M.2 2280 form factor and a PCI-Express 3.0 x4 interface with 3D NAND flash. Sequential speeds reach up to 3500 MB/s read and 3000 MB/s write. It is aimed at DIY enthusiasts, overclockers and graphics professionals who need large, fast storage.

Suits heavy workloads, not Gen4 slots

This drive suits users moving large project files, game libraries or video footage who want Gen3 endpoint performance. Random reads hit 290,000 IOPS and writes 240,000 IOPS, while SLC caching and a DRAM buffer smooth burst workloads. Endurance is rated at 2560 TBW with a 2,000,000-hour MTBF. Buyers whose motherboards only support PCIe 4.0 or 5.0 NVMe speeds should consider a newer-generation drive instead.

PCIe 3.0 x4 interface decides fit

The single specification that determines compatibility is the PCI-Express 3.0 x4 interface. Your motherboard must provide an M.2 slot wired for PCIe 3.0 (or backward-compatible 4.0/5.0) to run this SSD at its rated 3500/3000 MB/s. Without that link the drive will not operate at advertised throughput, so verify the slot generation before purchase.

Highlights

  • Sequential reads up to 3500 MB/s for fast system responsiveness
  • Sequential writes up to 3000 MB/s for quick file saves and installs
  • Random reads up to 290000 IOPS for snappy multitasking and game loads
  • 2560 TB written endurance with 2000000 hour MTBF for long-term reliability
  • Low active power draw of 0.33 W and idle 0.14 W for cooler operation

Specifications

BrandXPG
SeriesSX8100
ModelASX8100NP-4TT-C
Device TypeInternal (Desktop)
Used ForConsumer
Form FactorM.2 2280
Capacity4TB
Memory Components3D NAND
InterfacePCI-Express 3.0 x4
Max Sequential ReadUp to 3500 MBps
Max Sequential Write3000MB/s
4KB Random ReadUp to 290,000 IOPS
4KB Random WriteUp to 240,000 IOPS
Terabytes Written (TBW)2560TB
MTBF2,000,000 hours
HeatSinkwithout HeatSink
Power Consumption (Idle)0.14W
Power Consumption (Active)0.33W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Max Shock Resistance1500G
Height0.640
Width4.000
Depth5.000
Weight0.07

Questions about this item

What M.2 slot key and PCIe generation does my motherboard need for the SX8100 4TB?

The SX8100 4TB uses an M.2 2280 form factor with a PCIe 3.0 x4 NVMe interface, so your motherboard must provide an M-keyed M.2 slot wired for PCIe 3.0 x4 or higher.

Will the SX8100 4TB work in a system that only has PCIe 2.0 M.2 slots?

Yes, the drive is backward compatible and will operate in a PCIe 2.0 x4 slot, but sequential speeds will be limited to the 2.0 bandwidth ceiling instead of the rated 3500 MB/s read and 3000 MB/s write.

How can I verify the SX8100 4TB is delivering its rated performance after installation?

Run a sequential benchmark such as CrystalDiskMark; you should see reads approaching 3500 MB/s and writes near 3000 MB/s on a PCIe 3.0 x4 link, with 4K random results around 290,000 IOPS read and 240,000 IOPS write.
