Yeston Radeon RX 6500 XT graphics card with single fan cooler and black shroud

YESTON

Yeston Radeon RX 6500 XT 4GB GDDR6 graphics card

SKU CH-GJSA-8TPFZ

Entry-level desktop GPU with 4 GB GDDR6 on a 64-bit bus, PCIe 4.0, 1024 stream processors, boost to 2815 MHz, single-fan cooler, 107 W TDP, one HDMI 2.1 and one DisplayPort 1.4a

  • InterfacePCI Express 4.0
  • Chipset ManufacturerAMD
  • GPU SeriesAMD Radeon RX 6000 Series
  • GPURadeon RX 6500 XT
  • Core Clock2610MHz
  • Boost Clock2815MHz

Option RX 6500XT

  • RDNA 2 architecture on 6 nm process delivers efficient 1080p gaming
  • 1024 stream processors with 2815 MHz boost clock provide responsive frame rates
  • 4 GB GDDR6 on 64-bit bus supplies fast texture bandwidth
  • Single-fan cooler handles 107 W TDP within compact 175 mm length
  • HDMI 2.1 and DisplayPort 1.4a enable 7680 × 4320 output

4GB GDDR6 on a 64-bit bus

The Yeston Radeon RX 6500 XT is a desktop graphics card built around the AMD Navi 24 GPU fabricated on a 6nm process. It delivers 1024 stream processors with a core clock of 2610MHz and a boost clock of 2815MHz. The 4GB GDDR6 memory runs across a 64-bit interface and supports DirectX 12 for modern gaming workloads.

Upgrade from older entry-level GPUs

This card replaces ageing 4GB or 2GB models that lack PCI Express 4.0 bandwidth and RDNA 2 architecture features such as AMD FidelityFX Super Resolution and hardware-accelerated ray tracing. The jump is worth it when your current GPU cannot sustain 1080p gaming at medium settings or lacks DisplayPort 1.4a and HDMI 2.1 outputs for high-refresh displays.

Check PSU and case clearance first

Verify that your power supply meets the 500W recommendation and provides the required PCIe power connector for the 107W board. Ensure the chassis can accommodate the 175mm maximum card length and that the motherboard offers a PCI Express 4.0 x16 slot to avoid bandwidth constraints on the 64-bit memory bus.

Highlights

  • RDNA 2 architecture on 6 nm process delivers efficient 1080p gaming
  • 1024 stream processors with 2815 MHz boost clock provide responsive frame rates
  • 4 GB GDDR6 on 64-bit bus supplies fast texture bandwidth
  • Single-fan cooler handles 107 W TDP within compact 175 mm length
  • HDMI 2.1 and DisplayPort 1.4a enable 7680 × 4320 output

Specifications

BrandYeston
InterfacePCI Express 4.0
Chipset ManufacturerAMD
GPU SeriesAMD Radeon RX 6000 Series
GPURadeon RX 6500 XT
Core Clock2610MHz
Boost Clock2815MHz
Stream Processors1024
Memory Size4GB
Memory Interface64-Bit
Memory TypeGDDR6
DirectXDirectX 12
HDMI1 x HDMI 2.1
DisplayPort1 x DisplayPort 1.4a
Max Resolution7680 x 4320
CoolerSingle Fan
Thermal Design Power107W
Recommended PSU Wattage500W
Max GPU Length175 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What case clearance does the 175 mm card need?

The board measures 175 mm long, so the case must provide at least that much clear length from the rear bracket to any drive cage or cable.

Which power connector does the 107 W TDP require?

A single 6-pin PCIe connector from a 500 W supply feeds the 107 W TDP; the step often missed is seating the connector fully until the latch clicks.

When should the single fan be cleaned?

Dust the fan blades and heatsink fins every six to twelve months, or whenever temperatures rise noticeably under load.
