Green mining motherboard with twelve USB riser slots, CPU cooler, cables included

YINGHUA

YINGHUA B75 12GPU Mining Motherboard G1620 CPU SATA Cable Switch Cable 2xDDR3 USB3.0

SKU CH-ZY8B-M0EQC

Supports up to twelve GPUs with USB 3.0 connectivity and includes a G1620 CPU plus cables

  • CPU TypeIntel Atom
  • Supports up to 12 GPU connections for mining density
  • Includes G1620 processor ready for immediate deployment
  • Two memory slots accept up to 16 GB total capacity
  • Four SATA ports plus mSATA provide flexible storage options
  • USB 3.0 ports deliver faster data transfer speeds

YINGHUA B75 12GPU Mining Motherboard Kit

This kit combines a B75 chipset motherboard with an Intel G1620 processor, SATA cables and a switch cable. It is built for operators who need to run many graphics cards from a single board. The package includes the essential cables to connect storage and power the system quickly.

Suits miners expanding GPU density on a budget

The board offers twelve PCIe 1x slots routed through USB connections, four SATA ports and one MSATA connector for drive arrays. It also provides two USB 2.0 and two USB 3.0 ports at the rear plus one of each at the front. Builders who need integrated high-speed networking or native PCIe x16 slots should look at something else.

Twelve PCIe 1x slots via USB for GPU expansion

This single specification determines whether the board can host the number of cards a mining rig requires. The CPU socket is LGA 1155 and the chipset is B75, supporting memory up to 1600 MHz frequency. The network interface is a 100M LAN port and the board uses a 24-pin ATX plus 4-pin 12V power input.

Highlights

  • Supports up to 12 GPU connections for mining density
  • Includes G1620 processor ready for immediate deployment
  • Two memory slots accept up to 16 GB total capacity
  • Four SATA ports plus mSATA provide flexible storage options
  • USB 3.0 ports deliver faster data transfer speeds

Specifications

CPU TypeIntel Atom

Questions about this item

How many PCIe x1 graphics slots does the board provide for sustained mining?

The board offers 12 PCIe 1x slots that use USB transfer for graphics cards.

What is the rated speed of the onboard network interface when the system runs all day?

The integrated Realtek network card is rated at 100 M LAN speed.

Which power connectors must the existing PSU provide for this motherboard?

The board requires a 24-pin ATX power connector and a 4-pin ATX12V connector.
