Green rectangular M-ATX motherboard with LGA1151 socket, two DDR4 slots, PCIe x16, M.2, four SATA, HDMI, VGA, USB 2.0 and 3.0

YINGHUA

YINGHUA H110 server motherboard LGA1151 DDR4 G3900 CPU

SKU CH-MT7H-VDWR3

H110 micro-ATX board with LGA1151 socket, dual-channel DDR4 up to 32 GB, PCIe x16, M.2 NVMe, four SATA, Gigabit LAN and bundled G3900 CPU

  • CPU TypeIntel Atom
  • Supports Intel 6th/7th/8th gen CPUs via LGA1151 socket
  • Dual-channel DDR4 up to 32 GB at 2666 MHz
  • NVMe M.2 plus four SATA ports for fast storage
  • Gigabit LAN plus USB 3.0 and 2.0 for connectivity
  • Compact M-ATX form factor fits small server builds

H110 LGA1151 server board with G3900 CPU

This H110 motherboard uses the LGA1151 socket and ships with an Intel G3900 processor installed. It accepts 6th and 7th generation Intel Core i3, i5 and i7 CPUs built on the 14nm process. The M-ATX form factor suits compact server or desktop builds. Dual-channel DDR4 memory is supported up to 32 GB total across two slots.

PCIe 16x graphics and single M.2 NVMe slot

The board provides one PCI Express 16x slot for a discrete graphics card and a single M.2 NVMe slot for solid-state storage. Four SATA ports handle additional drives. Networking is supplied by a Gigabit LAN controller. Rear I/O includes two USB 3.0 ports, four USB 2.0 ports, VGA, HDMI, audio and RJ45 connectors.

32 GB DDR4 maximum memory capacity

Two 240-pin DDR4 slots support modules at 2133, 2400 and 2666 MHz with a combined ceiling of 32 GB. Builders needing more than 32 GB of system memory or a second M.2 NVMe drive should select a different platform. The included SATA cable and thermal grease simplify first assembly.

Highlights

  • Supports Intel 6th/7th/8th gen CPUs via LGA1151 socket
  • Dual-channel DDR4 up to 32 GB at 2666 MHz
  • NVMe M.2 plus four SATA ports for fast storage
  • Gigabit LAN plus USB 3.0 and 2.0 for connectivity
  • Compact M-ATX form factor fits small server builds

Specifications

CPU TypeIntel Atom

Questions about this item

Which included CPU should I choose between the G3900 and the G4560?

The G3900 is a dual-core processor while the G4560 adds hyper-threading for four threads.

What does the 2666 MHz memory rating mean once the board is running?

The board supports DDR4 up to 2666 MHz, but the actual speed will depend on the installed CPU and memory modules.

How does the PCI Express 16X slot and M.2 NVME slot limit expansion options?

The PCI Express 16X slot accepts graphics cards, while the M.2 slot supports NVME SSDs for fast storage.
