Black rectangular ATX power supply with 120mm fan and fixed cables

Zalman

Zalman GigaMax 700W ATX Power Supply Bronze Non-Modular

SKU CH-AJR8-HR6A3

Delivers 700 W with 80 PLUS Bronze efficiency, Active PFC, full protection suite, and a quiet 120 mm sleeve-bearing fan in a non-modular ATX design

  • TypeATX
  • Maximum Power700 W
  • ModularNon-Modular
  • Fans1
  • Main Connector20+4 Pin
  • PCI-Express Connector2 x 6+2-Pin

Options 700W

  • 80 PLUS Bronze certification delivers up to 85 % efficiency at typical loads
  • Active PFC reaches 99 % power factor for stable voltage under load
  • Six protection circuits guard against over current, over voltage, over power, over temperature, under voltage and short circuit
  • 120 mm sleeve-bearing fan runs quietly while keeping internal temperatures low
  • Two 6+2-pin PCIe connectors support dual graphics-card configurations

700 W ATX supply for mid-range builds

This 700 W ATX unit targets builders assembling mainstream desktops that need reliable power without modular cables. The Bronze efficiency rating and Active PFC keep wall draw lower under typical loads. All-black sleeved cabling on the 20+4 pin motherboard lead helps keep the interior tidy. Non-modular design means every cable stays attached.

Fixed cables and dual PCIe leads

Two 6+2-pin PCIe connectors support dual-GPU configurations such as CrossFireX or SLI setups. Three SATA power plugs handle storage drives and peripherals. The 120 mm sleeve-bearing fan runs quietly across the 0–40 °C operating range. Full protection suite covers OCP, OVP, OPP, OTP, UVP and SCP. Safety marks include cTUVus, TUV, FCC, CB, CE and EAC.

Bronze efficiency and thermal limits

Efficiency peaks at 85 % at 115 VAC typical load while meeting ErP 2013 Lot 6 standby requirements. MTBF exceeds 100,000 hours with 105 °C capacitors for high-voltage stability. Input spans 100–240 VAC at 50–60 Hz with a maximum power factor of 99 %. Compact 140 × 150 × 86 mm footprint fits standard ATX cases.

Highlights

  • 80 PLUS Bronze certification delivers up to 85 % efficiency at typical loads
  • Active PFC reaches 99 % power factor for stable voltage under load
  • Six protection circuits guard against over current, over voltage, over power, over temperature, under voltage and short circuit
  • 120 mm sleeve-bearing fan runs quietly while keeping internal temperatures low
  • Two 6+2-pin PCIe connectors support dual graphics-card configurations

Specifications

BrandZALMAN
Series80 Plus
TypeATX
Maximum Power700 W
ModularNon-Modular
Fans1
Main Connector20+4 Pin
PCI-Express Connector2 x 6+2-Pin
SATA Power Connector3
Efficiency> 82%
Energy-Efficient80 PLUS BRONZE Certified
Over Voltage ProtectionYes
Overload ProtectionYes
Input Voltage100 - 240 V
Input Frequency Range50/60 Hz
MTBF>100,000 Hours
ColorBlack
Max PSU Length5.9 x 5.5 x 3.4 inches
ProtectionCertified Full Protection: OCP/OVP/OPP/OTP/UVP/SCP, Safety/EMC Approvals: cTUVus, TUV, FCC, CB, CE certified.
Power Rating700W
Dimensions140(L) x 150(W) x 86(H)mm
Weight3.5 lb
Fans Total Quantity1
Top Fans Size120mm
Top Fans Bearing TypeSleeve

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What ATX standard does the Zalman GigaMax 700W follow and what efficiency does it guarantee?

It follows Intel ATX 12V Ver 2.31 and is 80 PLUS Bronze certified, guaranteeing up to 85% efficiency at typical loads.

What are the exact dimensions and weight for case fitment?

The unit measures 140 mm long, 150 mm wide, 86 mm high and weighs 1.6 kg.

How do I connect the 6+2 pin PCIe cables for a dual-GPU setup and what mistake should I avoid?

Plug each 6+2 pin connector directly from the PSU into each graphics card; do not daisy-chain a single cable to both cards.
