ZOTAC RTX 5070 Apocalypse OC graphics card, 2.5-slot black shroud with three fans and metal backplate

ZOTAC

ZOTAC RTX 5070 12GB Apocalypse OC graphics card

SKU CH-17R2-MJN54

GeForce RTX 5070 graphics card with 12GB GDDR7 memory, 6144 cores at 2587 MHz, PCIe 5.0, triple DisplayPort 2.1b and HDMI 2.1b, 2.5-slot cooler, 250W TDP

  • Chipset ManufacturerNVIDIA
  • Memory Size12GB
  • Memory Interface192-Bit
  • Memory TypeGDDR7
  • HDMI1 x HDMI
  • DisplayPort3 x DisplayPort 2.1b
  • 6144 stream processors accelerate AI and raster workloads
  • 12GB GDDR7 at 28 Gbps on a 192-bit bus feeds high-resolution textures
  • 2587 MHz core clock boosts frame rates in demanding titles
  • PCIe 5.0 x16 and DisplayPort 2.1b UHBR20 ready for 4K 480Hz or 8K 165Hz
  • Ice Mirror copper-base heatsink in a 2.5-slot design keeps thermals controlled

Target Build

This graphics card is built around the NVIDIA GeForce RTX 5070 GPU and suits enthusiasts who want high refresh rates at 4K or entry level 8K. It occupies 2.5 slots and measures 338mm by 134mm by 53mm so verify case clearance before purchase. The 12GB GDDR7 frame buffer and 192-bit bus target creators and gamers who need capacity without moving to a larger die.

Memory Subsystem

The single specification that decides fit is the 12GB GDDR7 memory running at 28 Gbps across a 192-bit interface. This combination fixes both total capacity and peak bandwidth so the card either meets a workload's VRAM ceiling or it does not. No other spec changes that binary outcome.

Sustained Load Behaviour

Under continuous load the 250W power draw is managed by the Ice Mirror Copper Base Apocalypse heatsink while the 12V-2x6 16P connector feeds stable current. A 750W supply is recommended to keep voltage rails steady during long render or compute sessions. Core clocks hold at 2587 MHz and memory at 28 Gbps without the throttling seen in short burst tests.

Highlights

  • 6144 stream processors accelerate AI and raster workloads
  • 12GB GDDR7 at 28 Gbps on a 192-bit bus feeds high-resolution textures
  • 2587 MHz core clock boosts frame rates in demanding titles
  • PCIe 5.0 x16 and DisplayPort 2.1b UHBR20 ready for 4K 480Hz or 8K 165Hz
  • Ice Mirror copper-base heatsink in a 2.5-slot design keeps thermals controlled

Specifications

Brandzotac
SeriesApocalypse
ModelRTX5070 12GB Apocalypse
Chipset ManufacturerNVIDIA
Memory Size12GB
Memory Interface192-Bit
Memory TypeGDDR7
HDMI1 x HDMI
DisplayPort3 x DisplayPort 2.1b
Max Resolution7680 x 4320
Card Dimensions (L x H)338mm x 134mm x 53mm
Slot Width2.5 Slots

Questions about this item

What does the 2587 MHz core clock mean once the card is installed in a system?

It is the boost clock the GPU targets under load; actual frequency depends on temperature, power limit and the workload being run.

What does PCI Express 5.0 x16 cap in practice for this GPU?

The slot provides up to 5.0 x16 bandwidth; the card will run at that speed when the motherboard supports PCIe 5.0, otherwise it falls back to 4.0 or 3.0 without loss of function.

What clearance and power connections are needed to fit the 338 mm long, 2.5-slot card?

A case with at least 338 mm GPU length clearance, 2.5-slot width space, a 750 W power supply and one 12V-2x6 connector (or the bundled 2×8-pin adapter).
