ZOTAC X GAMING GeForce RTX 5070 12GB graphics card, 2.5-slot dark cooler with three fans, metal backplate, 16-pin power connector

ZOTAC

ZOTAC X GAMING GeForce RTX 5070 12GB graphics card

SKU CH-6PPD-8G5XC

12 GB GDDR7 graphics card with 6144 CUDA cores, 2587 MHz boost clock and PCIe 5.0 x16 interface

  • InterfacePCI Express 5.0 x16
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce RTX 50 Series
  • GPUGeForce RTX 5070
  • ArchitectureBlackwell
  • Core Clock2542 MHz
  • 12 GB GDDR7 memory feeds high-resolution textures at 28 Gbps
  • 6144 CUDA cores accelerate ray-tracing and AI workloads
  • PCI Express 5.0 x16 doubles host bandwidth for modern platforms
  • Ice Mirror copper-base cooler handles 250 W in a 2.5-slot design
  • Three DisplayPort 2.1b and one HDMI 2.1b drive four displays up to 4K 480 Hz

ZOTAC X GAMING RTX 5070 12GB Overview

The ZOTAC X GAMING GeForce RTX 5070 12GB is a graphics card built on the NVIDIA Blackwell architecture. It features 6144 CUDA cores with a core clock of 2542 MHz and a boost clock of 2542 MHz. The card carries 12GB of GDDR7 memory across a 192-bit bus running at 28 Gbps. It targets gamers and creators who want current-generation performance at 1440p or 4K.

PCI Express 5.0 and 750W Power Requirements

The card installs in a PCI Express 5.0 x16 slot and occupies 2.5 slots in the chassis. It draws up to 250W through a single 12V-2x6 16-pin connector, with a 2x8-pin adapter included in the box. A 750W power supply is recommended. Display outputs include three DisplayPort 2.1b ports with UHBR20 and one HDMI 2.1b port, supporting up to four monitors simultaneously.

Ice Mirror Copper Base Cooling Under Load

The Ice Mirror Copper Base Apocalypse Cooler manages the 250W thermal load during extended gaming or rendering sessions. The copper base makes direct contact with the GPU to move heat into the heatsink array efficiently. The card measures 338mm long, 134mm wide and 53mm thick, and a support bracket is supplied to prevent sag. Drivers require Windows 10 64-bit version 1809 or later, or Windows 11.

Highlights

  • 12 GB GDDR7 memory feeds high-resolution textures at 28 Gbps
  • 6144 CUDA cores accelerate ray-tracing and AI workloads
  • PCI Express 5.0 x16 doubles host bandwidth for modern platforms
  • Ice Mirror copper-base cooler handles 250 W in a 2.5-slot design
  • Three DisplayPort 2.1b and one HDMI 2.1b drive four displays up to 4K 480 Hz

Specifications

BrandZOTAC
SeriesX GAMING
ModelRTX5070 12GB X GAMING
InterfacePCI Express 5.0 x16
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce RTX 50 Series
GPUGeForce RTX 5070
ArchitectureBlackwell
Core Clock2542 MHz
Boost Clock2542 MHz
CUDA Cores6144
Effective Memory Clock28 Gbps
Memory Size12GB
Memory Interface192-Bit
Memory TypeGDDR7
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support4
HDMI1 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b
ColorGray
Max Resolution7680 x 4320
CrossFireX SupportNo
Virtual Reality ReadyYes
CoolerTriple Fans
Operating Systems SupportedWindows 11 / Windows 10 64-bit (v1809
November 2018 or later) ‍👉Check gaming pc with Windows 11 Pro
Thermal Design Power250W
Recommended PSU Wattage750W
Power Connector1 x 16-Pin
FeaturesSPECIFICATIONS
• NVIDIA GeForce RTX 5070 GPU
• 6144 CUDA cores
• 12GB GDDR7 memory
• 192-bit memory bus
• Engine boost clock: 2512 MHz
• Memory clock: 28 Gbps
• PCI Express 5.0 x16
Form FactorATX
Max GPU Length320 mm
Card Dimensions (L x H)320mm x 117mm x 53mm
Slot Width2.5 Slots
Package ContentsINSIDE THE BOX
• ZOTAC GAMING GeForce RTX5070 12GB X GAMING
• User Manual
• 2 x 8-pin-to-16-pin cable
• GPU Support Stand

Questions about this item

When does the 250 W power draw become the limiting factor during extended load?

The card is rated for 250 W typical board power, so the 12V-2x6 connector and a 750 W supply set the ceiling once sustained work pushes the GPU to its 2587 MHz boost clock.

How loud and hot does the Ice Mirror Copper Base Apocalypse Cooler get after hours of full utilisation?

The 2.5-slot cooler uses a copper base and multiple heat pipes to move 250 W away from the GPU; fan speed ramps with temperature, so acoustics rise only when core heat approaches the thermal limit.

Which power supply and case clearance do I need before installing this 338 mm long graphics card?

A 750 W PSU with a native 12V-2x6 16-pin connector (or the bundled 2×8-pin adapter) and at least 338 mm of clear length plus 2.5-slot width are required.
