ZOTAC XGAMING RTX 5070 Ti 16GB triple-fan graphics card with dark metal shroud and backplate

ZOTAC

ZOTAC XGAMING GeForce RTX 5070 Ti 16GB graphics card

SKU CH-M1SR-86E24

16GB GDDR7 graphics card with 8960 CUDA cores, 256-bit bus, PCIe 5.0 and triple-fan cooling for 4K gaming

  • InterfacePCI Express 5.0 x16
  • Chipset ManufacturerNVIDIA
  • GPU SeriesNVIDIA GeForce RTX 50 Series
  • GPUGeForce RTX 5070 Ti
  • ArchitectureBlackwell
  • Core Clock2482 MHz
  • 16GB GDDR7 memory drives high-resolution texture performance
  • 28 Gbps effective memory clock feeds the 256-bit bus with massive bandwidth
  • 8960 CUDA cores accelerate ray-traced and AI workloads
  • PCI Express 5.0 x16 interface removes host-bus bottlenecks
  • DisplayPort 2.1b and HDMI 2.1b outputs support 4K 480Hz and 8K 165Hz displays

ZOTAC RTX 5070 Ti 16GB XGAMING

This ZOTAC XGAMING graphics card uses the NVIDIA GeForce RTX 5070 Ti GPU with 8960 CUDA cores and 16GB of GDDR7 memory on a 256-bit bus. It connects through a PCI Express 5.0 x16 slot and draws up to 285W. The card targets 4K gaming and creative workloads that benefit from high memory bandwidth and DLSS 4.0 support.

12V-2x6 power and 2.5-slot fit

Installation requires a 750W power supply and the included 12V-2x6 adapter cable. The 2.5-slot thickness and 320mm length mean clearance should be checked against the case and CPU cooler. The triple-fan cooler exhausts heat into the chassis, so front-to-rear airflow must be adequate to avoid recirculation.

285W sustained load behaviour

Under continuous load the GPU runs at its 285W power limit and the triple-fan cooler maintains stable clocks without throttling. GDDR7 memory at 28 Gbps stays within spec during long render or compute sessions. DisplayPort 2.1b and HDMI 2.1b outputs support 4K 120Hz HDR and 8K 60Hz HDR for extended use.

Highlights

  • 16GB GDDR7 memory drives high-resolution texture performance
  • 28 Gbps effective memory clock feeds the 256-bit bus with massive bandwidth
  • 8960 CUDA cores accelerate ray-traced and AI workloads
  • PCI Express 5.0 x16 interface removes host-bus bottlenecks
  • DisplayPort 2.1b and HDMI 2.1b outputs support 4K 480Hz and 8K 165Hz displays

Specifications

BrandZOTAC
SeriesXGAMING
ModelRTX 5070 Ti 16GB XGAMING
Part NumberRTX 5070 Ti 16GB XGAMING
InterfacePCI Express 5.0 x16
Chipset ManufacturerNVIDIA
GPU SeriesNVIDIA GeForce RTX 50 Series
GPUGeForce RTX 5070 Ti
ArchitectureBlackwell
Core Clock2482 MHz
CUDA Cores8960
Effective Memory Clock28 Gbps
Memory Size16GB
Memory Interface256-Bit
Memory TypeGDDR7
DirectXDirectX 12 Ultimate
OpenGLOpenGL 4.6
Multi-Monitor Support4
HDMI1 x HDMI 2.1b
DisplayPort3 x DisplayPort 2.1b
Max Resolution7680 x 4320
CrossFireX SupportNo
SLI SupportNo
CoolerTriple Fans
Thermal Design Power285W
Recommended PSU Wattage750W
Power Connector1 x 16-Pin
HDCP ReadyYes
FeaturesKEY FEATURES
• NVIDIA Blackwell Architecture
• 5th Generation Tensor cores
• 4th Generation RT cores
• NVIDIA DLSS 4
• Game Ready and NVIDIA Studio Drivers
• NVIDIA® GeForce Experience™
• NVIDIA Broadcast, NVIDIA G-SYNC
Form FactorATX
Max GPU Length320 mm
Card Dimensions (L x H)13.07 x 5.41 x 2.74 Inch
Slot Width2.5 Slots
Package ContentsINSIDE THE BOX
• ZOTAC GEFORCE RTX 5070 Ti 16GB XGAMING OC
• User Manual
• 3 x 8-pin-to-16-pin cable
• SPECTRA LINK cable
• GPU Support Stand

Questions about this item

How do I confirm the GPU is running at its 2482 MHz core clock and 28 Gbps memory speed after installation?

Open the NVIDIA control panel or a monitoring tool such as GPU-Z and verify the core clock reads 2482 MHz while the memory shows 28 Gbps under load.

What cables and adapters are included in the box and what must I supply myself?

The package contains the graphics card, a manual, and one 2x 8-pin to 16-pin power adapter; you must provide a 750 W power supply with native 12V-2x6 or spare 8-pin connectors.

Which version of this card should I choose if I need four simultaneous displays at up to 4K 480 Hz?

This single XGAMING model already provides three DisplayPort 2.1b outputs and one HDMI 2.1b port, supporting quad-display at 4K 480 Hz with DSC.
