Small black 40x10mm case fan with two wires

Zyvpee

Zyvpee AFB0412MA 40x10mm 12V 0.1A 2-pin ball bearing case fan

SKU CH-8BE6-R7MHN

A compact 40 x 10 mm case fan with ball bearing, 12 V 0.1 A power and a 2-pin connector running below 1600 RPM

  • TypeCase Fan
  • Bearing TypeBall
  • RPM<1600 RPM
  • Power Connector2 Pin
  • ColorBlack
  • LEDNon-LED
  • Compact 40×10 mm size fits tight chassis spaces
  • Ball bearing runs below 1600 RPM for quiet, long-life cooling
  • 12 V, 0.1 A draw keeps power load minimal
  • Two-pin connector enables simple plug-and-play installation
  • Non-LED black frame suits clean, distraction-free builds

40×10 mm ball-bearing case fan

The Zyvpee AFB0412MA is a 40 mm square, 10 mm thick case fan that runs on 12 V DC and draws 0.1 A. Its two-pin power connector and non-LED black frame suit compact chassis, small-form-factor PCs, or network gear such as routers and switches that need targeted airflow.

Two-pin installation and common pitfalls

The fan connects directly to a 2-pin header or a 12 V molex adapter; polarity must match the red and black wires to avoid damage. No PWM or speed-control wire is present, so the fan runs at full voltage whenever powered. The ball bearing tolerates any mounting orientation, but the thin 10 mm profile leaves little screw engagement — use the correct length fasteners to avoid stripping the frame.

Sustained-load behaviour at <1600 RPM

At its rated speed below 1600 RPM the fan delivers steady airflow for continuous duty in confined spaces. Ball bearings maintain consistent acoustic output over long periods without the wear-in noise sometimes seen in sleeve designs. Because the unit lacks speed modulation, thermal headroom depends entirely on the host system’s ability to supply constant 12 V power.

Highlights

  • Compact 40×10 mm size fits tight chassis spaces
  • Ball bearing runs below 1600 RPM for quiet, long-life cooling
  • 12 V, 0.1 A draw keeps power load minimal
  • Two-pin connector enables simple plug-and-play installation
  • Non-LED black frame suits clean, distraction-free builds

Specifications

BrandZyvpee
SeriesAFB0412MA
ModelAFB0412MA
TypeCase Fan
Bearing TypeBall
RPM<1600 RPM
Power Connector2 Pin
ColorBlack
LEDNon-LED
Features4CM Case Fan
Dimensions40*10MM

Questions about this item

How can I confirm the fan is spinning correctly after installation?

Listen for smooth rotation at up to 1600 RPM and feel steady airflow from the 40 mm frame.

What comes in the box and what must I source separately?

The Zyvpee AFB0412MA fan with its 2-pin power lead is included; mounting screws and a 12 V power header are not.

Which version should I choose for a 12 V 0.1 A header?

Select the AFB0412MA model rated at 12 V 0.1 A with a 2-pin connector to match that header.
