Green circuit board with black metal bracket and single RJ45 port

Intel

Intel EXPI9301CTBLK network card 10/100/1000Mbps PCI-Express

SKU CH-JFGG-DEGPT MPN EXPI9301CTBLK

Gigabit PCI-Express network adapter with one RJ45 port, auto-negotiation and low-power operation

  • Speed10/100/1000Mbps
  • Connectors1 x RJ45
  • InterfacePCI-Express
  • Wake On LANYes
  • Temperature0°C ~ 55°C
  • Humidity90% non-condensing relative humidity at 35° C
  • Gigabit speeds up to 1000 Mbps for fast LAN transfers
  • PCI Express dedicated I/O bus keeps full bandwidth available
  • Auto-negotiation selects the highest link speed of 10, 100 or 1000 Mbps
  • Low-power Intel 82574L controller reduces CPU load and energy draw
  • Wake-on-LAN plus teaming support enable remote management and server use

Desktop gigabit networking

The Intel EXPI9301CTBLK is a PCI-Express network adapter built around the 82574L controller. It gives desktop PCs a single RJ45 port for 10, 100 or 1000Mbps wired connections. The card targets users who need a reliable wired link without using a motherboard port.

Low-profile PCIe card with single RJ45

A standard bracket fits full-height slots and the board uses a x1 edge connector. One RJ45 jack handles the cable and auto-negotiates the highest available speed. Wake-on-LAN lets the system power up from a network signal. No extra brackets or cables are required for installation.

Efficient operation within standard limits

The adapter draws little power and runs without active cooling. Rated operating range is 0°C to 55°C with 90% non-condensing humidity at 35°C. Low heat output keeps case airflow undisturbed during sustained transfers. Silent operation suits quiet workstations and entry-level servers alike.

Pontos fortes

  • Gigabit speeds up to 1000 Mbps for fast LAN transfers
  • PCI Express dedicated I/O bus keeps full bandwidth available
  • Auto-negotiation selects the highest link speed of 10, 100 or 1000 Mbps
  • Low-power Intel 82574L controller reduces CPU load and energy draw
  • Wake-on-LAN plus teaming support enable remote management and server use

Especificações

BrandIntel
ModelEXPI9301CTBLK
Speed10/100/1000Mbps
Connectors1 x RJ45
InterfacePCI-Express
Wake On LANYes
Temperature0°C ~ 55°C
Humidity90% non-condensing relative humidity at 35° C
FeaturesHigh performance and reliability; low power
Delivers increased performance while significantly reducing CPU usage
Peso de envio0.07 kg
Dimensões da embalagem151 × 138 × 25 mm

Perguntas sobre este artigo

What practical speed limit does the PCI-Express interface impose on this 10/100/1000Mbps card?

The PCI-Express bus provides dedicated I/O bandwidth so the adapter can sustain full gigabit throughput without sharing the bus with other devices.

What slot type and bracket height does the EXPI9301CTBLK require to fit in a desktop chassis?

It installs in any standard PCI-Express slot and uses a low-profile bracket suitable for compact or full-height cases.

Which driver step is most often missed when installing the Intel 82574L-based adapter?

After seating the card, install the Intel PROSet driver package before connecting the cable; otherwise the link may stay at 100Mbps instead of negotiating 1000Mbps.
