Black 4U rackmount server chassis with ten front drive bays

iStarUSA Inc.

iStarUSA Inc. D410-DE12BK 4U 10-Bay Server Chassis

SKU CH-8Z6M-RE8BR MPN D410-DE12BK

4U rackmount chassis with 10 hot-swap 3.5" SAS/SATA bays, two 5.25" bays and 120 mm side cooling

  • Chassis TypeRackmount
  • Form Factor4U
  • ColorBlack
  • Case MaterialSteel
  • Motherboard Compatibility12 x 13 (EATX, ATX, microATX)
  • External 5.25" Drive Bays2

Model D410-DE12BK

  • D-410
  • D410-DE12BK
  • D-410-DE36

As versões riscadas existem, mas não estão disponíveis aqui.

  • Twelve hot-swap bays for high-density SAS or SATA storage
  • Seven full-length slots support full-height expansion cards
  • Two 120 mm side fans deliver direct airflow across drives
  • EATX board compatibility fits 12 x 13 inch server motherboards
  • Two 5.25 inch external bays allow optical or accessory installation

4U rackmount server chassis for dense storage

The iStarUSA D410-DE12BK is a 4U rackmount chassis built for environments that need high drive density in a standard rack. It accepts EATX, ATX and microATX motherboards up to 12 x 13 inches. The steel construction and black finish suit professional server rooms and cluster deployments.

Twelve hot-swap bays and two 5.25 inch slots

Twelve 3.5 inch SAS/SATA hot-swap bays allow drive changes without shutting down the system, while two external 5.25 inch bays remain available for optical drives or accessories. Seven expansion slots support full-length, full-height add-in cards. Two 120mm side fans direct airflow across the drive bays and motherboard area.

Replaces smaller enclosures when drive count grows

This chassis replaces 2U or tower cases once storage needs exceed their internal bay limits. The jump is worth it when a project requires twelve hot-swap drives and multiple full-height cards in a single 4U space. Builders who need fewer than ten drives or who cannot accommodate a 4U rack height should consider a smaller form factor.

Pontos fortes

  • Twelve hot-swap bays for high-density SAS or SATA storage
  • Seven full-length slots support full-height expansion cards
  • Two 120 mm side fans deliver direct airflow across drives
  • EATX board compatibility fits 12 x 13 inch server motherboards
  • Two 5.25 inch external bays allow optical or accessory installation

Especificações

BrandiStarUSA
ModelD410-DE12BK
Chassis TypeRackmount
Form Factor4U
ColorBlack
Case MaterialSteel
Motherboard Compatibility12 x 13 (EATX, ATX, microATX)
External 5.25" Drive Bays2
Hot-Swap Drive Bays12 x 3.5" SAS/SATA
Expansion Slots7
Peso de envio16.58 kg
Dimensões da embalagem724 × 584 × 311 mm

Outras versões deste modelo

Mais 2 nesta gama

Mesma família, memória, ventoinha ou frequência diferentes — compare antes de decidir.

Perguntas sobre este artigo

Does the chassis use a SAS or SATA backplane for the hot-swap bays?

The hot-swap bays accept both 3.5-inch SAS and SATA drives, so the backplane supports either interface without a speed cap imposed by the chassis itself.

What motherboard sizes fit the D410-DE12BK and how many expansion slots are available?

It accepts EATX, ATX and microATX boards up to 12 by 13 inches and provides seven full-length, full-height expansion slots.

How are the hot-swap drives installed and what common step is missed?

Drives slide directly into the trayless BPN-DE bays; the step often missed is pushing the drive until the latch clicks to engage the hot-swap connector.
