Small rectangular e-paper display board with 40-pin header and exposed solder pads, matte finish

LORDWORLD

LORDWORLD 2.13 Inch 250x122 e-Paper Display HAT Development Board

SKU CH-1AP6-TDST1

2.13-inch e-paper display HAT with 250x122 resolution retains images without power and connects via 40-pin GPIO or SPI pads for Raspberry Pi, Jetson Nano, and 3.3V/5V MCUs

  • Retains image without power thanks to zero-backlight e-paper
  • Ultra-low consumption — energy needed only during refresh cycles
  • 40-pin GPIO header fits Raspberry Pi boards and Jetson Nano
  • SPI solder pads allow connection to Arduino, Nucleo or other MCUs
  • Onboard voltage translator supports 3.3 V and 5 V logic

Compact 2.13 Inch e-Paper HAT

The LORDWORLD 2.13 inch e-Paper Display HAT is a development board with a 250x122 resolution E-Ink screen. It connects via a standard Raspberry Pi 40PIN GPIO header and includes an onboard voltage translator for 3.3V and 5V MCU compatibility. Preserved SPI solder pads allow connection to other controller boards.

Ideal for low-power static displays

This board suits makers building battery-powered sensors, price tags or status panels that retain an image without power. It is not for projects needing video rates, colour output or backlit viewing in darkness. Buyers who want touch input or higher pixel density should look at something else.

Drops onto a Pi header and frees GPIO

The HAT sits directly on a Raspberry Pi 2B, 3B, 3B+, 4B or Zero series board and also supports Jetson Nano. The 40PIN extension header passes unused GPIO through for additional peripherals. Only the SPI lines are consumed by the display, leaving the remaining pins free for sensors or actuators.

Pontos fortes

  • Retains image without power thanks to zero-backlight e-paper
  • Ultra-low consumption — energy needed only during refresh cycles
  • 40-pin GPIO header fits Raspberry Pi boards and Jetson Nano
  • SPI solder pads allow connection to Arduino, Nucleo or other MCUs
  • Onboard voltage translator supports 3.3 V and 5 V logic

Especificações

BrandLORDWORLD

Perguntas sobre este artigo

Does this HAT need a Raspberry Pi with the 40-pin GPIO header to operate?

Yes, the board uses the standard 40-pin header and works with Raspberry Pi 2B, 3B, 3B+, 4B, Zero and Zero W models.

Can I drive this e-paper display from an Arduino that runs at 5 V?

The onboard voltage translator makes the SPI interface compatible with both 3.3 V and 5 V microcontrollers, so an Arduino can be connected via the solder pads.

How can I verify the display is refreshing correctly after wiring it up?

Run a test script that writes a full-screen pattern; the 250 by 122 pixel panel should update without a backlight and retain the image when power is removed.
