Small silver desktop switch with five RJ45 ports and status LEDs

Netgear Inc.

Netgear Inc. GS305EP-100NAS 5-port Gigabit PoE+ network switch 63W

SKU CH-G7XJ-YGT97 MPN GS305EP-100NAS

A 5-port Gigabit desktop switch with four PoE+ ports sharing a 63W budget and smart Layer 2 features including VLAN, QoS and port mirroring

  • Switch Typemanaged
  • FormatDesktop Wall Mountable
  • StandardsIEEE 802.3 Ethernet IEEE 802.3ab 1000BASE-T IEEE 802.3u 100B
  • Network Management TypeSmart
  • Primary Ports5 x RJ45
  • Primary Port Speed10/100/1000Mbps

Model GS305EP

  • GS305
  • GS305E
  • GS305EP
  • GS305EPP

As versões riscadas existem, mas não estão disponíveis aqui.

  • 5 Gigabit ports deliver dedicated 1000 Mbps bandwidth per port
  • 4 PoE+ ports supply 63W total for IP cameras and access points
  • Smart managed features include VLAN, QoS and port mirroring
  • Fanless desktop or wall-mount design runs silently in any office
  • 9216-byte jumbo frames and 192KB buffer handle large data transfers

Five-port Gigabit switch with PoE+

This five-port Gigabit switch delivers 1000 Mbps per port and supplies up to 63 W of PoE+ power across four ports. It is built for small offices or home offices that need to power wireless access points, IP cameras or VoIP phones without separate injectors. The fanless, desktop or wall-mountable chassis runs silently in quiet environments.

Upgrade from unmanaged or non-PoE switches

Moving from an unmanaged switch adds VLAN segmentation, QoS prioritisation and per-port PoE control through a browser-based GUI. The jump is worthwhile when you need to separate guest traffic, guarantee bandwidth for voice or video, or remotely cycle power on a frozen device without climbing a ladder.

Sustained load with 63 W budget and fanless cooling

Under continuous full PoE load the 63 W budget is shared across the four powered ports, while the fanless design relies on passive convection within the 0 °C to 40 °C operating range. The 192 KB buffer and 9216-byte jumbo frames absorb traffic bursts, and uninterrupted PoE keeps endpoints powered during firmware updates or software reboots.

Pontos fortes

  • 5 Gigabit ports deliver dedicated 1000 Mbps bandwidth per port
  • 4 PoE+ ports supply 63W total for IP cameras and access points
  • Smart managed features include VLAN, QoS and port mirroring
  • Fanless desktop or wall-mount design runs silently in any office
  • 9216-byte jumbo frames and 192KB buffer handle large data transfers

Especificações

BrandNETGEAR
Part NumberGS305EP-100NAS
Switch Typemanaged
FormatDesktop
Wall Mountable
StandardsIEEE 802.3 Ethernet
IEEE 802.3ab 1000BASE-T
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
EEE 802.1p Class of Service
IEEE 802.1Q VLAN Tagging
IEEE 802.3x Full-duplex Flow Control
Network Management TypeSmart
Primary Ports5 x RJ45
Primary Port Speed10/100/1000Mbps
MAC Address Table4K
VLAN Support64 VLANs
Jumbo Frames9216 bytes
Buffer Memory192KB
PoE4 (PoE+) Budget 63W
QoSYes
Layer2
Port MirroringYes
LEDsPer port: Speed, Link, Activity, PoE
Per device: Power, system, PoE Max
PowerPoE (RJ-45) Port: Yes
PoE Budget: 63 W
Power Source: Power Adapter
TemperatureOperating temperature: 32° to 104°F (0° to 40°C)
Storage temperature: -4° to 158°F (-20° to 70°C)
HumidityOperating Humidity (relative): 90% maximum relative (RH), non-condensing
Storage Humidity (relative): 95% maximum relative humidity (RH), non-condensing
Package Contents5-Port Gigabit Ethernet SOHO Smart Managed Plus PoE Switch with 4-Port PoE+
Power Adapter
Wall Installation Kit
Rubber Feet
Installation Guide
Peso de envio1.04 kg
Dimensões da embalagem267 × 165 × 86 mm

Outras versões deste modelo

Mais 1 nesta gama

Mesma família, memória, ventoinha ou frequência diferentes — compare antes de decidir.

Perguntas sobre este artigo

How much desk or wall space does the GS305EP need for its desktop format and wall-mountable design?

The switch uses a compact desktop footprint and includes wall-mount slots, so it fits on a shelf or can be screwed to a wall without a rack.

What is the correct order to connect the power adapter and PoE devices so the 63 W budget is recognised?

Plug the external power adapter into the switch first, wait for the Power LED to turn solid green, then connect PoE devices to the four PoE+ ports.

When should the fanless GS305EP be cleaned to keep its 0 °C to 40 °C operating range reliable?

Vacuum dust from the ventilation slots every six to twelve months, or sooner in dusty environments, to maintain passive cooling performance.
