Aqua blue duplex fiber patch cable with FC connectors on both ends, 50 m length, 3.0 mm jacket

Enfain

Enfain OM3 FC-FC Duplex Multimode Patch Cable 50m

SKU CH-20ZE-7V6FN

A 50 m OM3 duplex patch cable with FC connectors, 3.0 mm jacket, 850 nm wavelength, typical 0.2 dB insertion loss and >38 dB return loss

Length 50m

  • Reliable 10 Gb links with OM3 50 µm core
  • Low typical insertion loss of .2 dB for efficient signal transfer
  • High return loss above 38 dB minimises reflection
  • Durable 3.0 mm PVC jacket rated for 1000 mating cycles
  • Wide operating range from -20 °C to +60 °C

Enfain OM3 FC-FC Duplex 50m Cable

This Enfain OM3 multimode patch cable uses FC-FC duplex connectors and spans 50 metres. It is built for 10 Gigabit Ethernet links inside data centres, server rooms or campus networks. The aqua jacket identifies the OM3 grade at a glance.

Suits 10G OM3 links with FC ports

It suits installers who need a 3.0 mm PVC jacket, ceramic ferrules and OM3 bandwidth at 850 nm. Buyers who require single-mode reach, LC or SC connectors, or a different jacket rating should look elsewhere.

Insertion loss 0.2 dB typical 0.3 dB max

The typical insertion loss is 0.2 dB and the maximum is 0.3 dB, with return loss exceeding 38 dB. Those figures decide whether the cable meets your link-loss budget for 1G, 10G or 40G multimode runs.

Prednosti

  • Reliable 10 Gb links with OM3 50 µm core
  • Low typical insertion loss of .2 dB for efficient signal transfer
  • High return loss above 38 dB minimises reflection
  • Durable 3.0 mm PVC jacket rated for 1000 mating cycles
  • Wide operating range from -20 °C to +60 °C

Špecifikácie

Pre tento produkt zatiaľ nie sú zverejnené žiadne špecifikácie.

Ďalšie verzie tohto modelu

Ďalších 5 v tomto rade

Rovnaký rad, iná pamäť, chladič alebo frekvencia — porovnajte pred rozhodnutím.

Otázky k tomuto produktu

What speeds does the OM3 duplex FC-FC cable support in practice?

The OM3 core is rated for 1 Gbps, 10 Gbps and 40 Gbps Ethernet over 850 nm multimode links.

What physical space is needed to route the 3.0 mm jacket?

The cable has a 3.0 mm PVC jacket and a minimum bend radius of 330 mm, so allow that clearance behind the patch panel.

How do you seat the ceramic-ferrule FC connectors without damaging them?

Align the keyed FC plug, push straight in until the threaded collar engages, then hand-tighten only — over-torquing cracks the ceramic ferrule.
