Aqua blue duplex fibre patch cable with LC and ST connectors, 15m length

Enfain

Enfain OM3 LC-ST Duplex Multimode Fibre Optic Cable 15m Aqua Blue

SKU CH-RS78-8SBE6

A 15-metre aqua OM3 duplex patch cord with LC and ST ceramic ferrules, 3.0 mm PVC jacket, 850 nm wavelength, 0.2 dB typical insertion loss and >38 dB return loss for 10 GbE links

Length 15m

  • Supports 10G, 40G and 1G networks with OM3 10-gigabit core
  • Low typical insertion loss of .2dB and maximum .3dB for reliable links
  • High return loss exceeding 38dB reduces signal reflection
  • Durable 3.0mm PVC jacket withstands 1000 mating cycles
  • Operates from -20°C to +60°C with 330mm minimum bend radius

Product Identity

The Enfain OM3 duplex multimode fibre cable carries 10 Gb/s signals over 15 metres using an 850 nm wavelength. It is built for data-centre, server and switch links that require OM3 bandwidth.

Pre-Installation Checks

Verify that both endpoints accept LC and ST connectors in a duplex arrangement. Confirm the link budget can tolerate up to .3 dB insertion loss and that the operating environment stays between -20 °C and +60 °C.

Build Integration

The 3.0 mm PVC jacket withstands 1000 mating cycles and a 330 mm bend radius for rack routing. Return loss exceeds 38 dB to protect upstream transceivers. Ceramic ferrules maintain alignment across repeated patch-panel changes.

Prednosti

  • Supports 10G, 40G and 1G networks with OM3 10-gigabit core
  • Low typical insertion loss of .2dB and maximum .3dB for reliable links
  • High return loss exceeding 38dB reduces signal reflection
  • Durable 3.0mm PVC jacket withstands 1000 mating cycles
  • Operates from -20°C to +60°C with 330mm minimum bend radius

Špecifikácie

Pre tento produkt zatiaľ nie sú zverejnené žiadne špecifikácie.

Ďalšie verzie tohto modelu

Ďalších 5 v tomto rade

Rovnaký rad, iná pamäť, chladič alebo frekvencia — porovnajte pred rozhodnutím.

Otázky k tomuto produktu

What connectors and length does the Enfain OM3 cable have, and is anything else needed to use it?

The cable has LC and ST duplex connectors and is 15 metres long. No extra parts are required; plug it into matching ports on your switch or server.

Which OM3 multimode version should I choose for 10G, 40G or 1G links?

The OM3 10-gigabit core supports 1G, 10G and 40G multimode connections at 850 nm, so this single version covers all three speeds.

What does the 0.2 dB typical insertion loss mean when the cable is installed?

At 850 nm the typical loss is 0.2 dB and the maximum is 0.3 dB, leaving ample margin for 10G and 40G links within the 15 metre run.
