Dayton
Dayton 6K484 GP Motor 1 HP 3450 rpm 56 Frame
Single-phase capacitor-start motor delivers 1 hp at 3450 rpm with a 56 frame and totally enclosed fan-cooled design
- ColorN/A
- typeClosed Base
- 1 HP capacitor-start motor delivers 3450 rpm for high-speed fan applications
- Dual-voltage 115/208-230 V design suits residential and light-commercial wiring
- Totally enclosed fan-cooled enclosure protects windings in dusty or damp environments
- Auto thermal protection and continuous duty rating support uninterrupted operation
- Rigid 56-frame base allows all-angle mounting for flexible installation
Motor Overview
The Dayton 6K484 is a single-phase general-purpose motor rated at 1 hp and 3450 rpm in a 56 frame size. It suits equipment builders and maintenance teams needing a direct-drive replacement for pumps, fans or compressors where continuous duty is required.
Build Integration
The motor operates on 115/208-230V AC at 60 Hz and draws 13.6 amps at 115V or 6.9 to 6.8 amps at 208-230V. A rigid base and all-angle mounting simplify installation, while the reversible CW/CCW shaft rotation adapts to existing drive layouts without rewiring the driven load.
Sustained Operation
Totally enclosed fan-cooled construction with Class B insulation and a 1.0 service factor supports continuous running at up to 40 °C ambient. Automatic thermal protection resets after a cool-down period, and the capacitor-start design delivers consistent torque across the full duty cycle.
商品特色
- 1 HP capacitor-start motor delivers 3450 rpm for high-speed fan applications
- Dual-voltage 115/208-230 V design suits residential and light-commercial wiring
- Totally enclosed fan-cooled enclosure protects windings in dusty or damp environments
- Auto thermal protection and continuous duty rating support uninterrupted operation
- Rigid 56-frame base allows all-angle mounting for flexible installation
商品規格
| Brand | DAYTON |
|---|---|
| Color | N/A |
| type | Closed Base |
商品問答
What is the maximum ambient temperature the 1 HP 3450 rpm motor can handle before thermal protection triggers?
The motor is rated for a maximum ambient temperature of 40 degrees C and includes automatic thermal protection for continuous duty cycles.
How much current does the 56 frame motor draw at 115 volts versus 208-230 volts during all-day operation?
Full load amps are 13.6 A at 115 V and 6.9 to 6.8 A at 208-230 V, with a 1.0 service factor and Class B insulation.
Which mounting hardware and voltage supply must already be in place to install this rigid-base 56 frame motor?
You need a rigid 56 frame mounting base and a single-phase 115/208-230 V AC, 60 Hz supply; the shaft rotates CW or CCW for flexible installation.
