Green rectangular PCB with 16x slot and 60cm blue USB 3.0 cable

GIBORIY

GIBORIY PCI-E 1x to 16x Riser 009S expansion card

SKU CH-JXSY-TV9FD

Connects a graphics card to a 1x PCI-E slot using a 60cm USB 3.0 cable with 16x mechanical slot and SATA power option

  • TypeNo
  • Independent GPU power via 4-pin and dual 6-pin connectors
  • 180-degree adapter simplifies tight-chassis installation
  • 60 cm USB 3.0 cable allows flexible GPU placement
  • 4 solid capacitors deliver stable power to the card
  • Compact 130 x 44 x 12 mm board fits small mining frames

GPU mining riser kit

The GIBORIY 009S riser extends a single PCI-E 1x lane into a 16x physical slot so a graphics card can sit away from the motherboard. It targets builders assembling multi-GPU mining rigs who need flexible card placement.

1x lane bandwidth ceiling

The adapter connects through a 60cm USB 3.0 cable that carries only one electrical lane regardless of the 16x slot size. Throughput is therefore limited to the host platform’s single-lane PCI Express capability.

Dual 6-pin and SATA power options

On-board 4-pin plus two 6-pin connectors let the card draw auxiliary power directly, easing the motherboard slot load when several GPUs are installed. The included SATA 15-pin to 6-pin cable adapts common power-supply leads for this purpose.

商品特色

  • Independent GPU power via 4-pin and dual 6-pin connectors
  • 180-degree adapter simplifies tight-chassis installation
  • 60 cm USB 3.0 cable allows flexible GPU placement
  • 4 solid capacitors deliver stable power to the card
  • Compact 130 x 44 x 12 mm board fits small mining frames

商品規格

TypeNo

商品問答

Should I use the 4-pin or dual 6-pin power option for my graphics card?

Both are available on the board; choose the connector that matches your GPU power requirement to keep the load off the motherboard.

What does the 60 cm USB 3.0 cable length mean for my mining rig layout?

The cable lets you position the GPU up to 60 cm away from the motherboard slot, giving flexibility in tight chassis or open-air frames.

How does the x1-to-x16 riser affect bandwidth for mining?

The adapter carries an x1 electrical link over the USB 3.0 cable, so mining workloads run at x1 speed rather than full x16 bandwidth.
