Green square LGA 1151 processor with gold contacts and silver heat spreader

Intel

Intel Xeon E-2124G CM8068403654114 server processor

SKU CH-YQ59-CBYDR MPN CM8068403654114

Quad-core server processor with 3.4 GHz base clock, 4.5 GHz turbo, 8 MB L3 cache, integrated UHD Graphics P630 and 71 W TDP

  • NameE-2124G
  • CPU Socket TypeLGA 1151
  • Core NameCoffee Lake
  • # of CoresQuad-Core
  • # of Threads4
  • Operating Frequency3.4 GHz
  • Quad-core 3.4 GHz base clock handles steady workloads
  • 5 GHz max turbo frequency accelerates burst tasks
  • 8 MB L3 cache reduces memory latency for frequent data
  • Intel UHD Graphics P630 supports up to three displays
  • 71 W thermal design power limits cooling requirements

Intel Xeon E-2124G quad-core server processor

The Intel Xeon E-2124G is a quad-core server processor built on 14 nm Coffee Lake architecture. It targets entry-level servers and workstations that need reliable 64-bit compute with integrated graphics. The LGA 1151 socket fits Intel C246 chipset platforms. It suits IT managers deploying light virtualization or file services.

3.4 GHz base with 4.5 GHz turbo and 8 MB L3 cache

Four cores run at 3.4 GHz base frequency and can reach 4.5 GHz max turbo for burst workloads. Eight megabytes of L3 cache and dual-channel memory support provide headroom for typical database or web-serving tasks. Hyper-Threading is not supported, so thread-heavy applications will hit the four-thread limit quickly. The 71 W thermal design power defines the sustained power envelope.

71 W TDP with Intel UHD Graphics P630 and PCIe 3.0

The 71 W TDP allows cooling with standard server heatsinks in 1U or tower chassis. Integrated Intel UHD Graphics P630 runs at 350 MHz base up to 1.15 GHz max dynamic frequency and drives up to three displays for local management. PCI Express 3.0 lanes connect storage controllers or network adapters. Buyers needing more than four threads or higher memory bandwidth should consider other Xeon models.

商品特色

  • Quad-core 3.4 GHz base clock handles steady workloads
  • 5 GHz max turbo frequency accelerates burst tasks
  • 8 MB L3 cache reduces memory latency for frequent data
  • Intel UHD Graphics P630 supports up to three displays
  • 71 W thermal design power limits cooling requirements

商品規格

BrandIntel
SeriesIntel Xeon E
NameE-2124G
ModelCM8068403654114
CPU Socket TypeLGA 1151
Core NameCoffee Lake
# of CoresQuad-Core
# of Threads4
Operating Frequency3.4 GHz
Max Turbo Frequency4.5 GHz
L3 Cache8MB
Manufacturing Tech14 nm
64-Bit SupportYes
Hyper-Threading SupportNo
Memory Channel2
Virtualization Technology SupportYes
Integrated GraphicsIntel UHD Graphics P630
Graphics Base Frequency350 MHz
Max Dynamic Frequency1.15 GHz
PCI Express Revision3.0
Thermal Design Power71W
Cooling DeviceCooling device not included - Processor Only
出貨重量1.13 kg
包裝尺寸127 × 102 × 25 mm

商品問答

Will the LGA 1151 socket on this Xeon E-2124G accept my existing C246 chipset motherboard?

Yes, the processor uses the LGA 1151 socket and is compatible with the Intel C246 chipset, so it will fit your current board.

How can I verify the integrated UHD Graphics P630 is active after installing the CPU?

Connect a display to the motherboard video outputs; the graphics controller runs at a base frequency of 350 MHz and can reach 1.15 GHz max dynamic frequency.

Does the OEM package include a cooler or do I need to buy a separate 71 W-rated solution?

This is an OEM processor without a stock cooler; you must supply your own heatsink rated for at least 71 W thermal design power.
