LR-LINK LRES3029PF-OCP 25Gbps dual SFP28 OCP 3.0 network card
A dual-port 25 Gbps SFP28 OCP 3.0 network adapter with an Intel E810-XXVAM2 controller for server virtualisation and high-throughput workloads
- StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
- Speed25Gbps
- Connectors2 x SFP28
- InterfaceOpen Computer Project (OCP) 3.0
- Temperature0°C ~ 55°C
- Humidity0 % ~ 90 % (Non-condensing)
Class 25G
- 1000M, Quad RJ45
- 10G,Dual SFP
- 100G
- 25G
- 10G,Four
被劃上刪除線的選項確實存在，但本站並無供貨。
Ports 2 x SFP
- 2 x SFP
- 4 x RJ45
- 4 x SFP
被劃上刪除線的選項確實存在，但本站並無供貨。
Option Intel E810-XXVAM2(2*SFP28)
- Intel XL710BM1(4*SFP+)
- Intel 82599ES(2*SFP+)
- Intel I350AM4(4*RJ45)
- Intel E810-XXVAM2(2*SFP28)
- Intel E810-CAM2(2*QSFP28))
被劃上刪除線的選項確實存在，但本站並無供貨。
- Dual 25Gbps SFP28 ports deliver high-throughput connectivity
- OCP 3.0 form factor fits modern server chassis
- Intel E810-XXVAM2 controller enables I/O virtualisation
- Broad OS support covers Windows Server, Linux and VMware
- Operates reliably from 0 °C to 55 °C
LR-LINK LRES3029PF-OCP 25Gbps NIC
The LR-LINK LRES3029PF-OCP is a dual-port network interface card built for servers and workstations that need 25 Gbps Ethernet connectivity. It uses the Intel E810-XXVAM2 controller and fits OCP 3.0 slots. The card targets administrators upgrading rack-mount systems for virtualization, cloud workloads or high-throughput data distribution.
OCP 3.0 form factor with dual SFP28 ports
This card installs only in chassis that provide an OCP 3.0 mezzanine slot; it will not fit standard PCIe brackets. Two SFP28 cages accept 25 Gbps transceivers, direct-attach cables or active optical cables. The Intel E810-XXVAM2 controller handles I/O virtualization and packet-loss prevention across both ports.
25 Gbps per port for virtualized
Each port delivers 25 Gbps line rate, giving ample headroom for multi-tenant virtualization, storage replication and big-data clusters. The adapter operates from 0 °C to 55 °C in non-condensing humidity up to 90 %. It is not suited for environments that require 100 Gbps links or standard PCIe add-in installation.
商品特色
- Dual 25Gbps SFP28 ports deliver high-throughput connectivity
- OCP 3.0 form factor fits modern server chassis
- Intel E810-XXVAM2 controller enables I/O virtualisation
- Broad OS support covers Windows Server, Linux and VMware
- Operates reliably from 0 °C to 55 °C
商品規格
| Brand | Lr-link |
|---|---|
| Model | LRES3029PF-OCP |
| Standards | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x |
| Speed | 25Gbps |
| Connectors | 2 x SFP28 |
| Interface | Open Computer Project (OCP) 3.0 |
| Temperature | 0°C ~ 55°C |
| Humidity | 0 % ~ 90 % (Non-condensing) |
| Class | 25G |
其他版本
同系列還有 3 款
同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。
LR-LINK
LR-LINK LRES3012PF-OCP 2x SFP+ 10G OCP 3.0 network card
- IEEE802.3, IEEE802.…
- 10Gbps
US$219.99
0.00280431BTC
現貨
LR-LINK
LR-LINK LRES3026PF-OCP 100Gbps 2*QSFP28 OCP 3.0 network card
- IEEE802.3, IEEE802.…
- 100Gbps
US$556.99
0.00710021BTC
現貨商品問答
What does 25Gbps per port mean when the card is installed in a server?
Each SFP28 port can transfer up to 25 gigabits per second, giving the server two independent 25Gbps links for high-throughput workloads.
How does the OCP 3.0 interface limit the card's performance in practice?
The OCP 3.0 form factor carries the dual 25Gbps lanes directly to the system board, so the interface itself does not throttle the advertised line rate.
What physical slot and clearance does the LRES3029PF-OCP need to fit?
It requires an OCP 3.0 mezzanine slot and fits within the standard OCP 3.0 height envelope for 1U or 2U server chassis.
