Green low-profile PCIe card with eight Mini-SAS ports

LSI

LSI MegaRAID 9240-8i 8-Port RAID Controller Card

SKU CH-PFH5-6GAEM

Eight-port SATA/SAS RAID controller with PCIe 2.0 x8 interface supporting RAID levels 0, 1, 5, 10, and 50 via Mini-SAS SFF-8087 connectors

  • Eight internal ports simplify storage expansion
  • PCIe 2.0 x8 interface enables high-speed data throughput
  • Supports RAID 0, 1, 5, 10, 50 for flexible data protection
  • Mini-SAS SFF-8087 connectors streamline internal cabling
  • Low-profile design fits space-constrained server chassis

8-Port RAID Controller for Servers

The LSI MegaRAID 9240-8i adds eight internal Sata and SAS ports through a single PCIe 2.0 x8 slot. It targets administrators who need hardware RAID on platforms that still use the PCIe 2.0 generation.

Low-Profile Card with Mini-SAS Connectors

A low-profile bracket fits space-constrained chassis while two SFF-8087 Mini-SAS headers keep cabling tidy. The universal compatibility claim covers servers and desktops that expose a PCIe x8 lane, so installation follows standard server-board layouts.

Hardware RAID Offload for Mixed Drive Types

The on-board processor handles RAID 0, 1, 5, 10 and 50 without burdening the host CPU, supporting both HDDs and SSDs at up to 6Gb/s per port. Power draw and thermals stay within typical add-in card limits for passively cooled server environments.

商品特色

  • Eight internal ports simplify storage expansion
  • PCIe 2.0 x8 interface enables high-speed data throughput
  • Supports RAID 0, 1, 5, 10, 50 for flexible data protection
  • Mini-SAS SFF-8087 connectors streamline internal cabling
  • Low-profile design fits space-constrained server chassis

商品規格

BrandIntel
ModelController RAID
Part Number9240-8i

商品問答

What does the PCIe 2.0 x8 interface limit in practice?

The PCIe 2.0 x8 link caps throughput to the bus bandwidth, so eight 6Gb/s SATA or SAS drives share that ceiling.

What slot and bracket does the card need to fit?

It requires a PCIe x8 slot and uses a low-profile bracket for space-constrained chassis.

How is the MegaRAID 9240-8i installed, and what step is often missed?

Seat the card in a PCIe x8 slot, connect drives to the two SFF-8087 Mini-SAS ports, then enter the BIOS utility to create the virtual disk before the OS sees it.
