Silver 18.5 inch all-in-one touchscreen panel PC with flat front and aluminum alloy fanless chassis

partaker

partaker A12-PA-190TPC-CE6B(J19)-8G128G 18.5" all-in-one PC

SKU CH-07J2-7DPBX

18.5-inch industrial all-in-one PC with IP65 front panel, 10-point capacitive touch, Intel Celeron J1900, 8GB DDR3, 128GB SSD, fanless aluminium cooling, Windows 10 Pro

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeCeleron
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel HD Graphics

GPU Intel HD Graphics

Memory 8GB DDR3

SSD

HDD None

  • None
  • 1TB

被劃上刪除線的選項確實存在，但本站並無供貨。

  • IP65 front-panel protection resists dust and water jets
  • Fanless aluminium chassis runs silently 24/7
  • 10-point capacitive touch handles multi-finger input
  • Intel Celeron J1900 quad-core delivers industrial-grade performance
  • VGA, 3 COM, USB 3.0, 2 USB 2.0, LAN provide extensive connectivity

Industrial panel PC with IP65 front

This 18.5 inch all-in-one computer combines an Intel Celeron J1900 processor with 8GB DDR3L memory and a 128GB mSATA SSD. The projected capacitive touchscreen supports 10-point input behind an IP65-rated front panel. Windows 10 Pro is pre-installed for immediate deployment in industrial environments.

Embedded mounting with buckle kits

Installation uses the supplied embedded buckle kits for panel-mount integration into a 454 x 276.5mm cut-out. Fanless aluminium cooling removes moving parts but requires adequate airflow around the 54.5mm chassis depth. The 12V DC input accepts 100-240V AC via the included adapter. Verify cable routing for the VGA, three COM ports, USB 3.0, three USB 2.0, LAN and audio connections before final mounting.

Suited for kiosk and automation roles

The wide operating temperature range of 0 to 50°C with SSD and 10 to 95 percent humidity tolerance fits factory floors and outdoor kiosks. Buyers needing higher-resolution displays, fan-assisted cooling for sustained loads, or expansion beyond the Mini PCIe slot should evaluate alternative platforms. The fixed 8GB memory ceiling and single mSATA drive bay limit future upgrades.

商品特色

  • IP65 front-panel protection resists dust and water jets
  • Fanless aluminium chassis runs silently 24/7
  • 10-point capacitive touch handles multi-finger input
  • Intel Celeron J1900 quad-core delivers industrial-grade performance
  • VGA, 3 COM, USB 3.0, 2 USB 2.0, LAN provide extensive connectivity

商品規格

ModelA12-PA-190TPC-CE6B(J19)-8G128G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeCeleron
CPU Name2.00GHz
GPU/VGA TypeIntel HD Graphics
Memory Capacity8GB DDR3
HDDNo
Screen Size18.5"
TouchscreenYes

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

How can I confirm the 10-point projected capacitive touch screen is responding correctly after installation?

Open Windows 10 Pro and test multi-finger gestures; the 1366 x 768 panel should register up to 10 simultaneous touches across the full 18.5" area without dead zones.

Which items ship in the box and what must I source separately for the A12-PA-190TPC-CE6B(J19)-8G128G?

The package includes the panel PC, 12V power supply, power cord, embedded buckle kits and warranty card; Wi-Fi or 4G modules for the mini PCIe slot and SIM card are not included.

Should I choose the 8GB DDR3L 1333 RAM and 128GB mSATA SSD configuration or add a 2.5" SATA drive?

The unit already ships with 8GB DDR3L 1333 memory at its maximum and a 128GB mSATA SSD; add a 2.5" SATA SSD or HDD only if you need extra local storage beyond 128GB.
