Gray 12.1 inch fanless all-in-one panel PC with capacitive touch screen and aluminum alloy chassis

partaker

Partaker A26 12.1" Fanless Capacitive AI edge system i5-7200U 8GB 128GB

SKU CH-QD65-BG7AK

A 12.1-inch fanless all-in-one industrial panel PC with a capacitive multi-touch screen, IP65 front protection, dual Gigabit Ethernet, and an Intel Core i5-7200U processor running Windows 10 Pro

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 7th Gen
  • CPU NameIntel Core i5-7200U

A26 12.1" Capacitive I5 7200U 8GB RAM / 128GB SSD

  • Fanless aluminium alloy chassis runs silently in dusty environments
  • 1 inch capacitive touch screen delivers 1024x768 multi-touch clarity
  • IP65 front panel resists water and dust ingress
  • Dual Gigabit LAN plus four USB ports connect factory equipment
  • Intel Core i5-7200U with 8GB DDR4 and 128GB mSATA powers automation tasks

Industrial Edge Panel PC

The Partaker A26 is a 12.1-inch fanless all-in-one system built for AI edge workloads in harsh environments. Its IP65-rated capacitive touchscreen and aluminium alloy chassis deliver silent, maintenance-free operation from -20 to +60 °C. An Intel Core i5-7200U processor with 8 GB of DDR4 memory and a 128 GB mSATA drive runs Windows 10 Pro out of the box. Dual Gigabit Ethernet ports and legacy COM ports integrate directly with factory equipment.

Upgrade From Legacy Fan-Cooled Panels

This unit replaces older panel PCs that rely on active cooling and lack front-panel water resistance. The jump is worth it when dust, moisture or vibration cause frequent fan failures or unplanned downtime. Support for up to 32 GB of DDR4 and dual mini-PCIe slots allows expansion for wireless or additional I/O as automation needs grow. The configurable 9–36 V DC input option suits sites with unstable power.

Embedded or VESA Mount Install

Installation uses a 298.5 mm by 237 mm rectangular cutout for embedded mounting or standard VESA brackets for surface mounting. The single 12 V DC jack simplifies wiring, but the optional wide-voltage module must be specified at order time. Common issues include forgetting to enable COM port RS-485 mode in BIOS and overlooking the watchdog timer settings for unattended recovery.

商品特色

  • Fanless aluminium alloy chassis runs silently in dusty environments
  • 1 inch capacitive touch screen delivers 1024x768 multi-touch clarity
  • IP65 front panel resists water and dust ingress
  • Dual Gigabit LAN plus four USB ports connect factory equipment
  • Intel Core i5-7200U with 8GB DDR4 and 128GB mSATA powers automation tasks

商品規格

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 7th Gen
CPU NameIntel Core i5-7200U
Screen Size12.1"
Screen TypeMulti-Touch Screen

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

What panel cutout is needed to embed the 12.1-inch unit?

The embedded mounting cutout is 298.5 mm by 237 mm. The front panel meets IP65 rating for dust and water resistance. VESA mounting is also supported.

Which step is often missed when wiring the DC power input?

The system requires a 12 V DC source. An optional 9–36 V wide-range input is available only as a factory customisation; do not apply a wider voltage unless that option was ordered.

How much DDR4 memory can be added later to the two slots?

Two DDR4 SO-DIMM slots support up to 32 GB total. The mSATA storage slot and two mini-PCIe slots are also accessible for future expansion.
