Gray aluminum-alloy 15-inch IP65 panel PC with resistive touchscreen

partaker

partaker A27 AI edge system i5-6200U 32GB 512GB 15" IP65

SKU CH-7KC9-MC7C4

A 15 inch IP65-rated all-in-one PC with Intel Core i5-6200U, 32GB DDR4, 512GB storage, resistive touchscreen and fanless aluminium chassis

  • TypeAll-in-One PC
  • Form FactorAll-in-One
  • ColorGray
  • Operating SystemWindows 10 Pro
  • CPU TypeIntel Core i5 6th Gen
  • CPU NameIntel Core i5-6200U

A27 15" Resistive I5 6200U 32GB RAM / 512GB SSD

  • Reliable visuals in harsh settings with 15-inch 1024x768 IP65 front panel
  • Silent maintenance-free operation from fanless aluminium alloy chassis
  • Responsive multi-touch control via resistive screen rated for 50 million touches
  • Expandable connectivity with dual Gigabit LAN and dual mini PCIe slots
  • Wide industrial deployment supported by 9-36 V DC input and -20 to +60 °C range

Industrial panel PC for harsh environments

The Partaker A27 is a 15-inch all-in-one system built around an Intel Core i5-6200U processor with 32GB of DDR4 memory and a 512GB mSATA drive. Its IP65-rated front panel resists dust and water jets, while the fanless aluminium chassis operates silently from -20 to +60 °C. Windows 10 Pro comes pre-installed for immediate deployment in factory automation, kiosk or outdoor signage roles.

Resistive touchscreen and expansion slots

The default resistive touch layer supports multi-touch input and is rated for 50 million actuations, making it usable with gloves or a stylus. Two mini-PCIe sockets accept Wi-Fi, Bluetooth, 3G or 4G modules, and a SIM holder is provided for cellular connectivity. Dual Gigabit Ethernet ports, two configurable RS232/485 serial ports, four USB ports and an HDMI output handle peripheral and display connections without extra adapters.

Check mounting cutout and power supply

Verify that your enclosure can accommodate the 355x279 mm panel cutout required for embedded installation. The unit ships with a 12 V DC input; if your site uses a wider 9–36 V DC range, confirm the wide-voltage option is selected before ordering. Ensure serial devices match the RS232/485 pinout and that any mini-PCIe expansion cards fit the two available slots.

商品特色

  • Reliable visuals in harsh settings with 15-inch 1024x768 IP65 front panel
  • Silent maintenance-free operation from fanless aluminium alloy chassis
  • Responsive multi-touch control via resistive screen rated for 50 million touches
  • Expandable connectivity with dual Gigabit LAN and dual mini PCIe slots
  • Wide industrial deployment supported by 9-36 V DC input and -20 to +60 °C range

商品規格

TypeAll-in-One PC
Form FactorAll-in-One
ColorGray
Operating SystemWindows 10 Pro
CPU TypeIntel Core i5 6th Gen
CPU NameIntel Core i5-6200U
Screen Size15"
Screen TypeMulti-Touch Screen

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

How often will the resistive touchscreen need replacement under normal use?

The resistive touchscreen is rated for up to 50 million touches, so replacement is unlikely during typical service life.

What thermal limit appears first when the i5-6200U runs continuously at full load?

The operating temperature ceiling of +60 °C will be reached before any active cooling can respond, because the chassis is fanless.

How much power does the system draw when operating all day with the display at full brightness?

The unit accepts 12 V DC input (optional 9–36 V wide range) and the panel brightness is 350 cd/m²; exact wattage depends on peripheral load.
