Silver 15.6 inch all-in-one touchscreen panel PC with aluminium fanless housing

partaker

partaker A6-PA-156TPC-CE6A(J19) 15.6" All-in-One PC Intel Celeron J1900 4GB DDR3 128GB SSD

SKU CH-NDEB-3FZ1C

A 15.6-inch fanless all-in-one with IP65 front protection, 10-point capacitive touch, Intel Celeron J1900, 4GB DDR3L and 128GB SSD for embedded industrial use

  • Form FactorAll-in-One
  • ColorSilver
  • Operating SystemWindows 10 Pro
  • CPU TypeCeleron
  • CPU Name2.00GHz
  • GPU/VGA TypeIntel HD Graphics

GPU Intel HD Graphics

Memory 4GB DDR3

SSD

HDD None

  • None
  • 1TB

被劃上刪除線的選項確實存在，但本站並無供貨。

  • IP65 front-panel protection resists dust and water ingress
  • Fanless aluminium chassis operates silently in industrial settings
  • 10-point projected capacitive touchscreen enables precise multi-touch control
  • Rich legacy I/O includes three COM ports and VGA for equipment integration
  • Compact 15.6-inch all-in-one design simplifies embedded installation

Industrial All-in-One with IP65 Front Panel

This 15.6-inch panel PC integrates an Intel Celeron J1900 processor, 4GB DDR3L memory and a 128GB mSATA SSD into a fanless aluminium chassis. The projected capacitive touchscreen supports ten simultaneous touch points and is rated IP65 on the front for dust and water resistance. Windows 10 Pro is pre-installed for immediate deployment in industrial environments.

Compact Embedded Mounting with Mini PCIe Expansion

The unit fits a 386.5 by 236 mm cut-out and includes embedded buckle kits for panel mounting; VESA 75, wall, desktop and cantilever options are also supported. A full-size Mini PCIe slot with a SIM holder allows wireless or 4G modules to be added internally. Three COM ports, one VGA, three USB 2.0, one USB 3.0, LAN and audio I/O provide legacy and modern connectivity without external adapters.

Fanless Cooling Across Zero to Fifty Degrees

Passive heat dissipation through the aluminium housing keeps the system silent while operating from zero to fifty degrees Celsius with the installed SSD. The 12V DC input accepts 100 to 240V AC via the bundled adapter and includes automatic power-on after power failure. A hardware watchdog timer with 255 levels adds reliability for unattended operation.

商品特色

  • IP65 front-panel protection resists dust and water ingress
  • Fanless aluminium chassis operates silently in industrial settings
  • 10-point projected capacitive touchscreen enables precise multi-touch control
  • Rich legacy I/O includes three COM ports and VGA for equipment integration
  • Compact 15.6-inch all-in-one design simplifies embedded installation

商品規格

ModelA6-PA-156TPC-CE6A(J19)-4G128G
Form FactorAll-in-One
ColorSilver
Operating SystemWindows 10 Pro
CPU TypeCeleron
CPU Name2.00GHz
GPU/VGA TypeIntel HD Graphics
Memory Capacity4GB DDR3
HDDNo
Screen Size15.6"
TouchscreenYes

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

How far can the Intel Celeron J1900 push its clock speed before thermal limits engage?

The processor runs at 2.00 GHz base and can boost to 2.42 GHz; the fanless aluminium chassis relies on passive cooling, so sustained heavy loads will eventually hit the thermal ceiling of the sealed enclosure.

What are the noise and heat characteristics when the system runs continuously?

The unit is completely fanless, producing zero acoustic noise; heat is dissipated through the aluminium housing, keeping surface temperatures within the 0–50 °C operating range when an SSD is installed.

Which memory modules must I already have to expand the RAM to the maximum?

The board accepts one SODIMM DDR3L 1333 module, supporting up to 8 GB total; the 4 GB stick is already fitted in the single slot.
