Gray fanless aluminium mini PC, compact rectangular shape, industrial barebone form factor

partaker

Partaker I18 N100 8GB 128GB barebone mini PC

SKU CH-FX03-MVZTK

Fanless industrial mini PC with Intel N100, 8 GB DDR5, 128 GB SSD, dual 2.5 GbE, six COM ports and GPIO for automation

  • ColorGray
  • CPU TypeIntel Processor

I18 CPU N100 8GB RAM / 128GB SSD

  • Silent fanless aluminium chassis runs from -20 °C to +50 °C
  • Quad-core N100 up to 3.4 GHz drives triple 4K displays
  • Dual 2.5 GbE plus six COM and eight GPIO for industrial I/O
  • DDR5 4800 SODIMM up to 16 GB with M.2 2280 and 2.5 inch storage bays
  • Wide 12 V Phoenix input supports wake-on-LAN, PXE, watchdog and TPM 2.0

Partaker I18 N100 Mini PC

The Partaker I18 is a fanless barebone mini PC built around an Intel N100 quad-core processor with 8 GB of DDR5 memory and a 128 GB SSD. Its aluminium chassis dissipates heat silently across a -20 °C to +50 °C range. Industrial-grade I/O includes dual 2.5G Ethernet, six COM ports and isolated GPIO.

Industrial automation and signage deployments

This unit suits integrators who need silent, dust-proof operation in harsh environments and require legacy serial connectivity alongside modern 2.5G networking. It is not for buyers who need active cooling for sustained heavy workloads, discrete graphics performance, or a larger number of display outputs.

Triple 4K display via HDMI and Type-C

The integrated Intel UHD Graphics drives three independent 4K screens at 60 Hz through two HDMI ports and one USB Type-C connection, so the choice hinges on whether your application needs that specific multi-display capability.

商品特色

  • Silent fanless aluminium chassis runs from -20 °C to +50 °C
  • Quad-core N100 up to 3.4 GHz drives triple 4K displays
  • Dual 2.5 GbE plus six COM and eight GPIO for industrial I/O
  • DDR5 4800 SODIMM up to 16 GB with M.2 2280 and 2.5 inch storage bays
  • Wide 12 V Phoenix input supports wake-on-LAN, PXE, watchdog and TPM 2.0

商品規格

ColorGray
CPU TypeIntel Processor

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

How do I mount the I18 mini PC on a wall using the included hardware?

Use the standard wall-mount brackets that ship with the unit; attach them to the chassis, then secure the assembly to a flat surface with four screws, ensuring the finned aluminum case has at least 20 mm clearance for passive airflow.

Which storage drives can I add later and what slots do they use?

You can install one M.2 2280 SATA or PCIe x1 SSD in the M-key slot and one 2.5-inch SATA HDD or SSD in the internal bay; both are user-accessible after removing the bottom cover.

What is the maximum operating temperature before the N100 throttles?

The fanless chassis is rated for continuous operation up to 50 °C ambient with surface airflow; beyond that the processor will reduce clocks to stay within thermal limits.
