Gray fanless aluminum mini PC, compact box shape with front ports and rear I/O panel

partaker

Partaker I22 N100 16GB 512GB barebone mini PC

SKU CH-JPPJ-WGAGV

Fanless industrial mini PC with Intel N100 quad-core processor, 16 GB DDR4 memory, 512 GB SSD, dual Gigabit LAN, four COM ports and triple 4K display support for harsh environments

  • ColorGray
  • CPU TypeIntel Processor

I22 CPU N100 16GB RAM / 512GB SSD

  • Fanless aluminium chassis runs silently from -20 °C to +50 °C
  • Quad-core N100 reaches 3.4 GHz for responsive multitasking
  • Triple 4K output via dual HDMI and VGA
  • Dual Gigabit LAN plus four COM ports for industrial I/O
  • 16 GB DDR4 and 512 GB SSD pre-installed for instant deployment

Compact industrial barebone

The Partaker I22 is a fanless mini PC built around an Intel N100 quad-core processor that reaches 3.4 GHz. It ships with 16 GB of DDR4 memory and a 512 GB SSD installed. The aluminium chassis dissipates heat silently and is rated for continuous operation from -20 to +50 °C.

Suited for fixed automation and signage

This unit fits machine-control cabinets, medical carts, logistics gates and education kiosks that need dual Gigabit LAN, four COM ports and triple 4K display outputs. Buyers who require active cooling for sustained heavy compute loads, a larger number of expansion slots or a wider AC-input voltage range should look at other platforms.

Storage and memory headroom

The supplied 512 GB drive handles operating system, logs and local databases with room to spare. One M.2 2280 slot accepts an additional SATA or PCIe 3.0 x1 NVMe SSD, and a 2.5-inch SATA bay is available for bulk data. Memory is fixed at 16 GB with no free SODIMM slot for upgrades.

商品特色

  • Fanless aluminium chassis runs silently from -20 °C to +50 °C
  • Quad-core N100 reaches 3.4 GHz for responsive multitasking
  • Triple 4K output via dual HDMI and VGA
  • Dual Gigabit LAN plus four COM ports for industrial I/O
  • 16 GB DDR4 and 512 GB SSD pre-installed for instant deployment

商品規格

ColorGray
CPU TypeIntel Processor

其他版本

同系列還有 5 款

同系列產品，記憶體、散熱器或時脈不同 — 下單前請先比較。

商品問答

Does the Partaker I22 N100 barebone need a separate power supply to operate?

The unit ships with a 12 V DC barrel jack (5.5 × 2.5 mm) and requires an external 12 V adapter that you must already have or buy separately.

Can I keep using my existing VGA monitor alongside two HDMI displays?

Yes, the Intel UHD Graphics drives triple independent 4K outputs — two HDMI ports at 3840 × 2160 @ 60 Hz and one VGA port at 1920 × 1080 @ 60 Hz — so the older VGA screen works simultaneously.

How can I verify the fanless cooling is keeping the N100 within safe limits after installation?

Enter the BIOS/UEFI hardware-monitor screen or run a Linux sensors command; the CPU temperature should stay below the rated +50 °C operating ceiling under load.
